Spectracom SecureSync User Manual

SecureSync units produced before 2016 may not be equipped with the oscillator sensor. They
can be retrofitted, if so requested. For additional information, contact Technical Support (see
"Technical Support" on page559). As the front panel cooling fan is internal temperature con-
trolled, the fan may not always be in operation. However, the fan may momentarily turn on
each time SecureSync is power-cycled.
Units produced since 2016
Units produced since 2016 are often equipped with the Fan Control feature, which turns ON the
fan by default. This feature also allows for a custom temperature window to be set for the fan.
Fan Control Feature
The Web UI Fan Control feature allows you to define a temperature range for the fan to turn
OFF and ON.
Note: Units produced before Dec. 2015 are not equipped with the Fan Control
feature.
Does my unit have Fan Control?
To find out, navigate to the HOME screen. Your unit is equipped with the Fan Control
feature, if there is a GEAR icon displayed in the System Status panel:
To enable user-defined Fan Control:
The default fan setting is ALWAYS ON.
To apply custom fan temperature settings:
298
CHAPTER 4 • SecureSync User Reference Guide Rev. 26
4.5 Quality Management

Spectracom SecureSync Specifications

General

Model	SecureSync
Time Reference	GPS, GLONASS, BeiDou, Galileo, IRIG, NTP, PTP, 1PPS
Disciplines	GNSS, IRIG, PTP, NTP, SyncE
Inputs	GPS, GLONASS, BeiDou, Galileo, IRIG, NTP, PTP, 1PPS
Outputs	NTP, PTP, 1PPS, IRIG
Protocols	PTP, NTP, SNMP, SSH, HTTPS
Form Factor	1U Rack-mount
Redundancy	Optional redundant power supply
Security Features	Password protection, access control lists, SSH, HTTPS, SNMPv3, NTP authentication, PTP authentication
Power Supply	100-240 VAC, 50-60 Hz
Operating Temperature	0°C to +50°C
Dimensions	44.45 mm (H) x 482.6 mm (W)
