Spectracom SecureSync User Manual

BIT No. CF ELEMENT No. FUNCTION
77 26 SPACE
78 27 SPACE
79 PID P8 POSITION IDENTIFIER
80 28 SBS 20
81 29 SBS 21
82 30 SBS 22
83 31 SBS 23
84 32 SBS 24
85 33 SBS 25
86 34 SBS 26
87 35 SBS 27
88 36 SBS 28
89 PID P9 POSITION IDENTIFIER
90 37 SBS 29
91 38 SBS 210
92 39 SBS 211
93 40 SBS 212
94 41 SBS 213
95 42 SBS 214
96 43 SBS 215
97 44 SBS 216
98 45 SPACE
99 PID P0 POSITION IDENTIFIER
5.5.5 IRIG Output Accuracy Specifications
The IRIG outputs of the Spectracom Option Cards 1204-15, -1E, -22, and 1204-05, -27 deliver
signals with the following 1PPS accuracy:
558 SecureSync User Reference Guide
APPENDIX

Spectracom SecureSync Specifications

General

Model	SecureSync
Time Reference	GPS, GLONASS, BeiDou, Galileo, IRIG, NTP, PTP, 1PPS
Disciplines	GNSS, IRIG, PTP, NTP, SyncE
Inputs	GPS, GLONASS, BeiDou, Galileo, IRIG, NTP, PTP, 1PPS
Outputs	NTP, PTP, 1PPS, IRIG
Protocols	PTP, NTP, SNMP, SSH, HTTPS
Form Factor	1U Rack-mount
Redundancy	Optional redundant power supply
Security Features	Password protection, access control lists, SSH, HTTPS, SNMPv3, NTP authentication, PTP authentication
Power Supply	100-240 VAC, 50-60 Hz
Operating Temperature	0°C to +50°C
Dimensions	44.45 mm (H) x 482.6 mm (W)
