Spectracom SecureSync User Manual

5.2.1.1 Web UI Navigation: Option Cards
Figure 5-1: Option card navigation
To view or edit option card settings in the SecureSync Web UI (see also image above):
Status Summary panel
Under INTERFACES > OPTIONCARDS, clicking the superordinate list entry will open the
StatusSummary panel, which provides a status overview, as well as access to the Status
window and the Editwindow.
Status window
Under INTERFACES > OPTIONCARDS, clicking subordinate (indented) entries will open
the Status window, providing detailed option card status information.
Edit window
To edit option card settings, either click the Edit button in the lower-left corner of the
Status window, or click the GEAR button in the Status Summary panel: The Edit window will
open.
346 SecureSync User Reference Guide
APPENDIX

Spectracom SecureSync Specifications

General

Model	SecureSync
Time Reference	GPS, GLONASS, BeiDou, Galileo, IRIG, NTP, PTP, 1PPS
Disciplines	GNSS, IRIG, PTP, NTP, SyncE
Inputs	GPS, GLONASS, BeiDou, Galileo, IRIG, NTP, PTP, 1PPS
Outputs	NTP, PTP, 1PPS, IRIG
Protocols	PTP, NTP, SNMP, SSH, HTTPS
Form Factor	1U Rack-mount
Redundancy	Optional redundant power supply
Security Features	Password protection, access control lists, SSH, HTTPS, SNMPv3, NTP authentication, PTP authentication
Power Supply	100-240 VAC, 50-60 Hz
Operating Temperature	0°C to +50°C
Dimensions	44.45 mm (H) x 482.6 mm (W)
