Spectracom SecureSync User Manual

: Colon Separator
HH Hours (00-23)
MM Minutes (00-59)
SS Seconds (00-59) (00-60 for leap second)
Q Time Sync Status [as INPUT]
space = SYNC
‘.’ = SYNC
‘*’=NOT IN SYNC
‘#’ = NOT IN SYNC
“?” = NOT IN SYNC
Q Time Sync Status [as OUTPUT]
space = Time error is less than time quality flag 1's threshold (TFOM < or = 3)
“.” = Time error has exceeded time quality flag 1's threshold (TFOM = 4)
“*” = Time error has exceeded time quality flag 2's threshold (TFOM = 5)
“#” = Time error has exceeded time quality flag 3's threshold (TFOM = 6)
“?” = Time error has exceeded time quality flag 4's threshold OR a reference source is unavailable
(TFOM >=7)
CR Carriage Return (ASCII Character 13)
LF Line Feed (ASCII Character 10)
The leading edge of the first character (CR) marks the on-time point of the data stream.
5.4.12.1 Format 9S
Format 9S is a variation of ASCII Format 9 that uses Sysplex compatible fields indicating
sychronization status:
FL_SYNC_SYS_REF_NONE ('X') Never been in sync
FL_SYNC_SYS_REF_YES (' ') In sync with a reference
FL_SYNC_SYS_REF_LOST ('F') Out of sync, lost reference
SecureSync User Reference Guide 533
APPENDIX

Spectracom SecureSync Specifications

General

Model	SecureSync
Time Reference	GPS, GLONASS, BeiDou, Galileo, IRIG, NTP, PTP, 1PPS
Disciplines	GNSS, IRIG, PTP, NTP, SyncE
Inputs	GPS, GLONASS, BeiDou, Galileo, IRIG, NTP, PTP, 1PPS
Outputs	NTP, PTP, 1PPS, IRIG
Protocols	PTP, NTP, SNMP, SSH, HTTPS
Form Factor	1U Rack-mount
Redundancy	Optional redundant power supply
Security Features	Password protection, access control lists, SSH, HTTPS, SNMPv3, NTP authentication, PTP authentication
Power Supply	100-240 VAC, 50-60 Hz
Operating Temperature	0°C to +50°C
Dimensions	44.45 mm (H) x 482.6 mm (W)
