Spectracom SecureSync User Manual

T Time Figure of Merit character (TFOM), limited to the range 6 to 9:
9 indicates error >±10 milliseconds, or unsynchronized condition
8 indicates error <±10 milliseconds
7 indicates error <±1 millisecond
6 indicates error <±100 microseconds
YYYY Year
DDD Day of Year (001-366)
HH Hour of the day (00-23)
: Colon Separator
MM Minutes of the hour
SS Seconds (00-59), (00-60 for leap second)
z The sign of the offset to UTC, + implies time is ahead of UTC
ZZ The magnitude of the offset to UTC in units of half-hours.
If ZZ = 0, then z = +
m Time mode character, is one of:
G = GPS
L = Local
U = UTC
T = TAI
CR Carriage Return
LF Line Feed
5.4.16.2 EndRunX (Extended) Time Format
The EndRunX format is identical to the EndRun format, with the addition of two fields: the current
leap second settings and the future leap second settings.
T h e f o l l o w i n g e x a m p l e m e s s a g e s t r i n g i s s e n t
o n c e e a c h s e c o n d :
T YYYY DDD HH:MM:SS zZZ m CC FF<CR><LF>
Where:
542 SecureSync User Reference Guide
APPENDIX

Spectracom SecureSync Specifications

General

Model	SecureSync
Time Reference	GPS, GLONASS, BeiDou, Galileo, IRIG, NTP, PTP, 1PPS
Disciplines	GNSS, IRIG, PTP, NTP, SyncE
Inputs	GPS, GLONASS, BeiDou, Galileo, IRIG, NTP, PTP, 1PPS
Outputs	NTP, PTP, 1PPS, IRIG
Protocols	PTP, NTP, SNMP, SSH, HTTPS
Form Factor	1U Rack-mount
Redundancy	Optional redundant power supply
Security Features	Password protection, access control lists, SSH, HTTPS, SNMPv3, NTP authentication, PTP authentication
Power Supply	100-240 VAC, 50-60 Hz
Operating Temperature	0°C to +50°C
Dimensions	44.45 mm (H) x 482.6 mm (W)
