Spectracom SecureSync User Manual

Signature Control: Displays the current configuration of Signature Control. See also: "Sig-
nature Control" on page141.
Frequency: Indicates the configured frequency of the 1PPS output signal.
Offset: Displays the configured Offset (to account for cable delays or other latencies).
Edge: Shows if the on-time point of the 1PPS output is the rising or falling edge of the
pulse.
Pulse Width: Displays the configured Pulse Width of the 1PPS output. The Pulse Width is
displayed in nanoseconds (ns). The default Pulse Width is 200 milliseconds.
5.2.3.4 Frequency Out [1204-08, -1C, -26, -38]
Frequency Out [1204-08, -1C, -26, -38]: Specifications
Outputs: (3) 1MHz, (3) 5MHz, or (3) 10MHz Outputs
Signal Type and Connector:
(10MHz) +13dBm into 50Ω, BNC, or TNC (-38)
(5MHz) +10dBm into 50Ω, BNC, or TNC (-38)
(1MHz) +10dBm into 50Ω, BNC, or TNC (-38)
1MHz or 5MHz Phase Noise (with OCXO or low phase noise Rubidium oscillator):
-115dBc/Hz @ 10Hz
-130dBc/Hz @ 100Hz
-140dBc/Hz @ 1kHz
1MHz or 5MHz Phase noise (with Rubidium oscillator):
-85dBc/Hz @ 10Hz
-110dBc/Hz @ 100Hz
-130dBC/Hz @ 1kHz
10MHz Phase Noise (with TCXO oscillator):
-110dBc/Hz @ 100Hz
-135dBc/Hz @ 1kHz
-140dBc/Hz @ 10kHz
10MHz Phase Noise (with OCXO oscillator) [Numbers in brackets represent Low Phase
Noise OCXO option]:
384 SecureSync User Reference Guide
APPENDIX

Spectracom SecureSync Specifications

General

Model	SecureSync
Time Reference	GPS, GLONASS, BeiDou, Galileo, IRIG, NTP, PTP, 1PPS
Disciplines	GNSS, IRIG, PTP, NTP, SyncE
Inputs	GPS, GLONASS, BeiDou, Galileo, IRIG, NTP, PTP, 1PPS
Outputs	NTP, PTP, 1PPS, IRIG
Protocols	PTP, NTP, SNMP, SSH, HTTPS
Form Factor	1U Rack-mount
Redundancy	Optional redundant power supply
Security Features	Password protection, access control lists, SSH, HTTPS, SNMPv3, NTP authentication, PTP authentication
Power Supply	100-240 VAC, 50-60 Hz
Operating Temperature	0°C to +50°C
Dimensions	44.45 mm (H) x 482.6 mm (W)
