Spectracom SecureSync User Manual

2.
The Reboot/Halt window will display. Select the Shutdown the Unit checkbox.
3.
Click Submit.
4.
Wait 30 seconds after entering the HALT command before switching off the unit .
Once the HALT process has been initiated, the front panel LCD will display Power
offSecureSync, and the front panel LED time display will stop incrementing.
Issuing a HALT Command via Keypad/SerialPort/Telnet/SSH:
The HALT command can be initiated not only via the SecureSync WebUI, but also via the
keypad and LCD display. For more information on the keypad, see "Front Panel Keypad, and
Display" on page4.
With a serial connection to the front panel serial port, telnet connection or SSH connection,
type halt <Enter> to halt the unit for shutdown. For more information on SecureSync com-
mands, see "CLICommands" on page513.
Once the HALT process has been initiated, the front panel LCD will display Power off
SecureSync, and the front panel LED time display will stop incrementing.
Note: After issuing the HALT command wait 30 seconds before you remove
power.
4.1.4 Rebooting the System
To reboot SecureSync via the Web UI:
1.
Navigate to TOOLS > SYSTEM: Reboot/Halt.
238
CHAPTER 4 • SecureSync User Reference Guide Rev. 26
4.1 Powering Up/Shutting Down

Spectracom SecureSync Specifications

General

Model	SecureSync
Time Reference	GPS, GLONASS, BeiDou, Galileo, IRIG, NTP, PTP, 1PPS
Disciplines	GNSS, IRIG, PTP, NTP, SyncE
Inputs	GPS, GLONASS, BeiDou, Galileo, IRIG, NTP, PTP, 1PPS
Outputs	NTP, PTP, 1PPS, IRIG
Protocols	PTP, NTP, SNMP, SSH, HTTPS
Form Factor	1U Rack-mount
Redundancy	Optional redundant power supply
Security Features	Password protection, access control lists, SSH, HTTPS, SNMPv3, NTP authentication, PTP authentication
Power Supply	100-240 VAC, 50-60 Hz
Operating Temperature	0°C to +50°C
Dimensions	44.45 mm (H) x 482.6 mm (W)
