Spectracom SecureSync User Manual

Procedure:
1.
Connect the personal computer to the front panel serial connectorUSB interface, using
the serial cable.
2.
Configure your terminal emulation program, using the following settings:
Port: COM1
Bits per second: 9600
Data bits: 8
Parity: None
Stop bits: 1
Flow control: None
3.
Depending on which network protocol you are using (SSH, Telnet), you will need to
enter authentication upon establishment of the connection either in a separate authen-
tication window, or the Terminal window: The default user name is spadmin, and the
password admin123.
4.
Using the Terminal window, you can now submit commands; see "CLICommands"
below for a list of commands.
5.3.2 CLICommands
SecureSync features a suite of command-line interface (CLI) commands that can be used to con-
figure parameters and retrieve status information or log files via a remote connection, using the
telnet or ssh (if enabled) protocol.
This section includes a list of some of the supported commands.
SecureSync User Reference Guide 513
APPENDIX

Spectracom SecureSync Specifications

General

Model	SecureSync
Time Reference	GPS, GLONASS, BeiDou, Galileo, IRIG, NTP, PTP, 1PPS
Disciplines	GNSS, IRIG, PTP, NTP, SyncE
Inputs	GPS, GLONASS, BeiDou, Galileo, IRIG, NTP, PTP, 1PPS
Outputs	NTP, PTP, 1PPS, IRIG
Protocols	PTP, NTP, SNMP, SSH, HTTPS
Form Factor	1U Rack-mount
Redundancy	Optional redundant power supply
Security Features	Password protection, access control lists, SSH, HTTPS, SNMPv3, NTP authentication, PTP authentication
Power Supply	100-240 VAC, 50-60 Hz
Operating Temperature	0°C to +50°C
Dimensions	44.45 mm (H) x 482.6 mm (W)
