Spectracom SecureSync User Manual

Card
ID*
Card Name Name in UI See ...
28 1-in/3-out 1 PPS module (TTL
[BNC])
1PPS/Frequency
RS-485
"1PPS In/Out [1204-28, -2A]" on
page372
29 1-in/3-out HaveQuick module
(TTL [BNC])
HAVEQUICK
"HAVE QUICK In/Out [1204-29]" on
page449
2A 1-in/3-out 1 PPS module (Fiber
Optic)
1PPS In/Out,
Fiber
"1PPS In/Out [1204-28, -2A]" on
page372
2B Quad 1 PPS output module
(Fiber Optic)
1PPS Out, Fiber
"1PPS Out [1204-18, -19, -21, -2B]" on
page367
2F Programmable Frequency Out-
put module (TTL)
Prog Freq Out,
TTL
"Programmable Frequency Out [1204-
13, -2F, -30]" on page387
2E Revertive Selector module ("Fail-
over")
n/a
"Revertive Selector Card [1204-2E]" on
page500
3E STL input module STL
"STL Option Module [1204-3E]" on
page486
30 Programmable Frequency Out-
put module (RS-485)
Prog Freq Out,
RS-485
"Programmable Frequency Out [1204-
13, -2F, -30]" on page387
32 1Gb PTP module Gb PTP
"PTP Grandmaster [1204-32]" on
page469
38 10 MHz output module (3 x TNC
outputs)
10 MHz Out
"Frequency Out [1204-08, -1C, -26, -
38]" on page384
43 Single GNSS module GNSS Receiver
"GNSS Receiver [1204-43, -44]" on
page485
44 Dual GNSS module Dual GNSS
Receiver
"GNSS Receiver [1204-43, -44]" on
page485
1.5.3 Option Card Connectors
The table below lists the connector types used in SecureSync option cards.
Table 1-5:
Option card connectors
Connector Illustration Electr. Signals Timing signals
BNC Differential TTL xV, sine wave, programm.
square wave, AM sine wave, DCLS
1PPS, frequency,
IRIG, HAVE
QUICK,
PTP
ST Fiber Optic AM sine wave, DCLS IRIG, 1PPS
16
CHAPTER 1 • SecureSync User Reference Guide Rev. 26
1.5 Option Cards

Spectracom SecureSync Specifications

General

Model	SecureSync
Time Reference	GPS, GLONASS, BeiDou, Galileo, IRIG, NTP, PTP, 1PPS
Disciplines	GNSS, IRIG, PTP, NTP, SyncE
Inputs	GPS, GLONASS, BeiDou, Galileo, IRIG, NTP, PTP, 1PPS
Outputs	NTP, PTP, 1PPS, IRIG
Protocols	PTP, NTP, SNMP, SSH, HTTPS
Form Factor	1U Rack-mount
Redundancy	Optional redundant power supply
Security Features	Password protection, access control lists, SSH, HTTPS, SNMPv3, NTP authentication, PTP authentication
Power Supply	100-240 VAC, 50-60 Hz
Operating Temperature	0°C to +50°C
Dimensions	44.45 mm (H) x 482.6 mm (W)
