Spectracom SecureSync User Manual

Card
ID*
Card Name Name in UI See ...
10 HaveQuick output module (TTL) HAVE QUICK
Out, BNC
"HAVE QUICK Out [1204-10, -1B]" on
page443
11 STANAG output module STANAG Out
"STANAG Out [1204-11, -25]" on
page428
12 10/100 Mb PTP module (EOL) PTP "PTP Master/Slave [1204-12]" on page1
13 Programmable Frequency Out-
put module (Sine Wave)
Prog Freq Out,
Sine
"Programmable Frequency Out [1204-
13, -2F, -30]" on page387
14 CTCSS, Data Sync/Clock mod-
ule ("Simulcast")
Simulcast
"Simulcast (CTCSS/Data Clock) [1204-
14]" on page396
15 IRIG module, BNC (4 outputs) IRIG Out BNC
"IRIG Out [1204-15, -1E, -22]" on
page409
17 Square Wave (TTL) output mod-
ule
Sq Wv Out,
BNC
"Programmable Square Wave Out
[1204-17]" on page392
18 Quad 1 PPS output module (TTL) 1PPS Out BNC
"1PPS Out [1204-18, -19, -21, -2B]" on
page367
19 Quad 1 PPS output module (10
V)
1PPS Out 10V
"1PPS Out [1204-18, -19, -21, -2B]" on
page367
1B HaveQuick output module (RS-
485)
HAVEQUICK
Out, RS-485
"HAVE QUICK Out [1204-10, -1B]" on
page443
1C 10 MHz output module (3 out-
puts)
10 MHz Out
"Frequency Out [1204-08, -1C, -26, -
38]" on page384
1D STANAG input module STANAG In
"STANAG In [1204-1D, -24]" on
page435
1E IRIG module, Fiber Optic (4 out-
puts)
IRIGOut, Fiber
"IRIG Out [1204-15, -1E, -22]" on
page409
21 Quad 1 PPS output module (RS-
485 [terminal block])
1PPS Out, RS-
485
"1PPS Out [1204-18, -19, -21, -2B]" on
page367
22 IRIG module, RS-485 (4 outputs) IRIG Out, RS-
485
"IRIG Out [1204-15, -1E, -22]" on
page409
23 Event Broadcast module Event Broadcast
"Event Broadcast [1204-23]" on
page501
24 STANAG isolated input module STANAG In, Isol-
ated
"STANAG In [1204-1D, -24]" on
page435
25 STANAG isolated output module STANAG Out,
Isolated
"STANAG Out [1204-11, -25]" on
page428
26 1 MHz output module (3 outputs) 1MHz Out
"Frequency Out [1204-08, -1C, -26, -
38]" on page384
27 IRIG module, Fiber Optic (1
input, 1 outputs)
IRIG In/Out,
Fiber
"IRIG In/Out [1204-05, -27]" on
page415
1.5 Option Cards
CHAPTER 1 • SecureSync User Reference Guide Rev. 26
15

Spectracom SecureSync Specifications

General

Model	SecureSync
Time Reference	GPS, GLONASS, BeiDou, Galileo, IRIG, NTP, PTP, 1PPS
Disciplines	GNSS, IRIG, PTP, NTP, SyncE
Inputs	GPS, GLONASS, BeiDou, Galileo, IRIG, NTP, PTP, 1PPS
Outputs	NTP, PTP, 1PPS, IRIG
Protocols	PTP, NTP, SNMP, SSH, HTTPS
Form Factor	1U Rack-mount
Redundancy	Optional redundant power supply
Security Features	Password protection, access control lists, SSH, HTTPS, SNMPv3, NTP authentication, PTP authentication
Power Supply	100-240 VAC, 50-60 Hz
Operating Temperature	0°C to +50°C
Dimensions	44.45 mm (H) x 482.6 mm (W)
