Spectracom SecureSync User Manual

E x a m p l e :
FRI 20APR01 12:45:36
The example data stream provides the following information:
Sync
Status
The clock is not time synchronized to GNSS. Time is derived from the battery backed clock or
set manually
Date Friday, April 23, 2015
Time 12:45:36
5.4.6 Spectracom Format 1S
Format 1S (Space) is very similar to Format 1, with the exception of a space being the first char-
acter of Days 1 through 9 of each month (instead of the leading “0” which is present in Format
1).
Most external systems utilizing Data Format 1 will look for a single digit day of the month for
day 1 through day 9, with a space in front of each digit (^1, ^2, ^3 … 10, 11…) whereas
other systems need to see a two digit day of the month for all days 1 through 9 with a leading
0 instead of a space (01, 02, 03… 10, 11…).
If your device requires the single digit day of the month for days 1 through 9 (i.e. 1, 2,
etc.), select Format 1S.
If your device requires the two digit day of the month for days 1 through 9 (i.e. 01, 02,
etc.), select Format 1 instead. Refer to "Spectracom Format 1" on page521 for inform-
ation on Format 1.
E x a m p l e m e s s a g e :
CR LF I ^ WWW ^ DDMMMYY ^ HH:MM:SS CR LF
Where:
CR Carriage Return
LF Line Feed
I Time Sync Status (space, ?, *)
^ Space separator
WWW Day of Week (SUN, MON, TUE, WED, THU, FRI, SAT)
SecureSync User Reference Guide 523
APPENDIX

Spectracom SecureSync Specifications

General

Model	SecureSync
Time Reference	GPS, GLONASS, BeiDou, Galileo, IRIG, NTP, PTP, 1PPS
Disciplines	GNSS, IRIG, PTP, NTP, SyncE
Inputs	GPS, GLONASS, BeiDou, Galileo, IRIG, NTP, PTP, 1PPS
Outputs	NTP, PTP, 1PPS, IRIG
Protocols	PTP, NTP, SNMP, SSH, HTTPS
Form Factor	1U Rack-mount
Redundancy	Optional redundant power supply
Security Features	Password protection, access control lists, SSH, HTTPS, SNMPv3, NTP authentication, PTP authentication
Power Supply	100-240 VAC, 50-60 Hz
Operating Temperature	0°C to +50°C
Dimensions	44.45 mm (H) x 482.6 mm (W)
