Spectracom SecureSync User Manual

CONTENTS
SecureSync User Reference Guide • TABLE OF CONTENTS
III
CHAPTER 1
Product Description
1
1.1 Getting Started
2
1.2 SecureSync Introduction
2
1.2.1 SecureSync's Inputs and Outputs
3
1.3 SecureSync Front Panel
3
1.3.1 Front Panel Keypad, and Display
4
1.3.1.1 Using the Keypad
4
1.3.1.2 Navigating the Front Panel Display
4
1.3.2 Status LEDs
6
1.4 Unit Rear Panel
7
1.5 Option Cards
8
1.5.1 Option Cards Overview
10
1.5.2 Option Card Identification
13
1.5.2.1 Option Card Identification by ID/Part Number
13
1.5.3 Option Card Connectors
16
1.6 The SecureSync Web UI
18
1.6.1 The Web UI HOME Screen
18
1.6.2 The INTERFACES Menu
19
1.6.3 The Configuration MANAGEMENT Menu
20
1.6.4 The TOOLS Menu
21
1.7 Specifications
22
1.7.1 Input Power
22
1.7.1.1 Fuses
22
1.7.2 GNSS Receiver
23
1.7.3 RS-232 Serial Port (Front Panel)
23
1.7.4 10/100 Ethernet Port
23
1.7.5 Protocols Supported
24
1.7.6 1PPS Output
24
1.7.7 10 MHz Output
25
1.7.7.1 10 MHz Output — Oscillator Phase Noise (dBc/Hz)
26

Spectracom SecureSync Specifications

General

Model	SecureSync
Time Reference	GPS, GLONASS, BeiDou, Galileo, IRIG, NTP, PTP, 1PPS
Disciplines	GNSS, IRIG, PTP, NTP, SyncE
Inputs	GPS, GLONASS, BeiDou, Galileo, IRIG, NTP, PTP, 1PPS
Outputs	NTP, PTP, 1PPS, IRIG
Protocols	PTP, NTP, SNMP, SSH, HTTPS
Form Factor	1U Rack-mount
Redundancy	Optional redundant power supply
Security Features	Password protection, access control lists, SSH, HTTPS, SNMPv3, NTP authentication, PTP authentication
Power Supply	100-240 VAC, 50-60 Hz
Operating Temperature	0°C to +50°C
Dimensions	44.45 mm (H) x 482.6 mm (W)
