Spectracom SecureSync User Manual

4.5.2.6 Configuring Logs
Note: The NTP log has no available configuration options.
To configure a log:
1.
Navigate to MANAGEMENT > OTHER: Log Configuration.
2.
In the Logs panel select the log category you wish to configure e.g., System, then click the
PENCIL button next to it.
3.
In the Log File window, fill in the available fields (see below for explanations).
4.
Click Submit.
The following log configuration options are available:
a.
Add/Remove Remote Server: The Syslog server(s) to which remote logs are sent. This
panel is only available if Remote Log is checked below in the Log Configuration panel. If
the log has a remote log server to which it writes, the name of the server will appear
here. Click Delete to remove the remote server.
4.5 Quality Management
CHAPTER 4 • SecureSync User Reference Guide Rev. 26
313

Spectracom SecureSync Specifications

General

Model	SecureSync
Time Reference	GPS, GLONASS, BeiDou, Galileo, IRIG, NTP, PTP, 1PPS
Disciplines	GNSS, IRIG, PTP, NTP, SyncE
Inputs	GPS, GLONASS, BeiDou, Galileo, IRIG, NTP, PTP, 1PPS
Outputs	NTP, PTP, 1PPS, IRIG
Protocols	PTP, NTP, SNMP, SSH, HTTPS
Form Factor	1U Rack-mount
Redundancy	Optional redundant power supply
Security Features	Password protection, access control lists, SSH, HTTPS, SNMPv3, NTP authentication, PTP authentication
Power Supply	100-240 VAC, 50-60 Hz
Operating Temperature	0°C to +50°C
Dimensions	44.45 mm (H) x 482.6 mm (W)
