Spectracom SecureSync User Manual

After completion of the hardware installation, the Reference Priority configuration needs to be
restored, see STEP [12].
5.2.2.6 [3]: Determining the Installation Procedure
The installation procedure for option cards varies, depending on:
i.
option card model
ii.
installation slot chosen by you, and
iii.
for upper slots only: if the bottom slot is used or not.
Determining the correct installation procedure
a.
Identify the last two digits of the part number of your option card (see label on bag).
b.
Inspect the back of the SecureSync housing, and select an empty slot for the new card. If
the card is to be installed in one of the upper slots (2, 4, or 6), take note if the cor-
responding lower slot is occupied.
Figure 5-2: Unit rear view
c.
See table "Installation steps" below:
i.
Find your part number in the left-hand column.
ii.
Choose your Installation Location (as determined above).
iii.
If using an upper slot (2, 4, or 6), select either the Bottom Slot row "empty" or
"populated".
iv.
Note or highlight the PROCEDURE STEPS [x] for your installation scenario and fol-
low the procedure step by step.
Note: Follow only the PROCEDURE STEPS [x] listed for your option card and
installation scenario!
354 SecureSync User Reference Guide
APPENDIX

Spectracom SecureSync Specifications

General

Model	SecureSync
Time Reference	GPS, GLONASS, BeiDou, Galileo, IRIG, NTP, PTP, 1PPS
Disciplines	GNSS, IRIG, PTP, NTP, SyncE
Inputs	GPS, GLONASS, BeiDou, Galileo, IRIG, NTP, PTP, 1PPS
Outputs	NTP, PTP, 1PPS, IRIG
Protocols	PTP, NTP, SNMP, SSH, HTTPS
Form Factor	1U Rack-mount
Redundancy	Optional redundant power supply
Security Features	Password protection, access control lists, SSH, HTTPS, SNMPv3, NTP authentication, PTP authentication
Power Supply	100-240 VAC, 50-60 Hz
Operating Temperature	0°C to +50°C
Dimensions	44.45 mm (H) x 482.6 mm (W)
