Spectracom SecureSync User Manual

3.
Fill out the fields:
Host: The hostname or IP address of the RADIUS server
Port: Defines the RADIUS Port to use. The default RADIUS Port is 1812, but this can
be changed, as required.
Secret Key: The secret key which is shared by SecureSync and the RADIUS server
(the key is used to generate an MD5 hash).
Timeout: [seconds] Defines the Timeout that SecureSync will wait to communicate
with the RADIUS server e.g., 10 seconds.
4.
Click the Add Server button. A confirmation message The item has been added will be dis-
played if the server could be added, and the server will be added to the list, indicating
its status. The server status can be:
DISABLED: RADIUS service is disabled.
UNREACHABLE: This RADIUS server cannot be reached.
REACHABLE: This RADIUS server can be reached.
5.
To remove a RADIUS server from the list, click the X-button in the Actions column.
Note: SecureSync supports multiple RADIUS servers. The system performance, how-
ever, will be negatively affected by a large number of servers or invalid servers,
respectively.
264
CHAPTER 4 • SecureSync User Reference Guide Rev. 26
4.3 Managing Users and Security

Spectracom SecureSync Specifications

General

Model	SecureSync
Time Reference	GPS, GLONASS, BeiDou, Galileo, IRIG, NTP, PTP, 1PPS
Disciplines	GNSS, IRIG, PTP, NTP, SyncE
Inputs	GPS, GLONASS, BeiDou, Galileo, IRIG, NTP, PTP, 1PPS
Outputs	NTP, PTP, 1PPS, IRIG
Protocols	PTP, NTP, SNMP, SSH, HTTPS
Form Factor	1U Rack-mount
Redundancy	Optional redundant power supply
Security Features	Password protection, access control lists, SSH, HTTPS, SNMPv3, NTP authentication, PTP authentication
Power Supply	100-240 VAC, 50-60 Hz
Operating Temperature	0°C to +50°C
Dimensions	44.45 mm (H) x 482.6 mm (W)
