A local clock set up through the Time Management Page: This option will appear
under the name of the local clock you have set up. Refer to "The Time Man-
agement Screen" on page146 for more information on how to configure and
read the System Time. Local timescale allows a Local Clock to apply a time offset
for Time Zone and DST correction.
The incoming input time information may be provided as local time, but System Time
may be configured as UTC time, so internal computations need to be performed. With
the Timescale field set to “Local”, select the name of a previously created Local Clock.
The Time Zone and DST rules, as configured in the Local Clock will be applied to the
front panel time display. Refer to for more information on Local Clocks.
Offset: Provides the ability to account for HAVE QUICK cable delays or other latencies
in the HAVE QUICK outputs. The Offset values are entered in nanoseconds (ns). The avail-
able Offset range is –500 to +500 ms.
HAVE QUICK Output: Status Window
To view the current settings of a HAVE QUICK Output, go to its Status window. For instructions,
see: "Viewing Input/Output Configuration Settings" on page347.
The Web UI list entry for this card is: HAVE QUICK In/Out.
Outputs are named: HQ Output [number].
Note: SecureSync starts numbering I/O ports with 0 (only 1PPS and 10MHz out-
puts start at1, because of the built-in outputs).
The Status window displays the following settings:
Signature Control: Signature Control is used to control when the HAVE QUICK mod-
ulation is present, see "Signature Control" on page141.
Format: Used to configure the formatting of the four available HAVE QUICK outputs. The
available output formats are as follows:
454 SecureSync User Reference Guide
APPENDIX
