Spectracom SecureSync User Manual

Maximum Number of Cards: 1
Ordering Information: 1204-06: Gigabit Ethernet (3X) Module
Figure 5-53: 1204-06 option card rear plate
Network Setup
To monitor and manage Ethernet on SecureSync:
Navigate to MANAGEMENT > Network Setup. On the right side of the Network Setup
screen, the Ports panel will display the available Ethernet ports, and their connection
status:
Eth0 is the built-in SecureSync Ethernet port. Eth1 through eth3 are the ports provided by
the 1204-06 card.
To learn more about Ethernet setup, see "Configuring Network Settings" on page55.
Routing Tables
There are five (5) routing tables in the system: one for each network interface, and one main
routing table.
468 SecureSync User Reference Guide
APPENDIX

Spectracom SecureSync Specifications

General

Model	SecureSync
Time Reference	GPS, GLONASS, BeiDou, Galileo, IRIG, NTP, PTP, 1PPS
Disciplines	GNSS, IRIG, PTP, NTP, SyncE
Inputs	GPS, GLONASS, BeiDou, Galileo, IRIG, NTP, PTP, 1PPS
Outputs	NTP, PTP, 1PPS, IRIG
Protocols	PTP, NTP, SNMP, SSH, HTTPS
Form Factor	1U Rack-mount
Redundancy	Optional redundant power supply
Security Features	Password protection, access control lists, SSH, HTTPS, SNMPv3, NTP authentication, PTP authentication
Power Supply	100-240 VAC, 50-60 Hz
Operating Temperature	0°C to +50°C
Dimensions	44.45 mm (H) x 482.6 mm (W)
