Spectracom SecureSync User Manual

To configure PTP on the network:
1.
In the GB PTP Edit window, navigate to the Main tab.
2.
Under the Main tab of the GB PTP Edit window, make the following settings:
Domain Number: Sets the current PTP Domain Number, as defined in IEEE Std
1588-2008 Section 7.1
Clock Mode: See under "Main tab settings" on page472.
Enable DHCP: This is a checkbox to enable or disable the delivery of IP addresses
from a DHCP Server. The default setting is enabled (the box is checked).
Static IP Address: When a DHCP server is not requested or is requested but not
available, the PTP Module will use this IP address. In the format “#.#.#.#” with no
leading zeroes or spaces, where each ‘#’ is a decimal integer from the range
[0,255].
Network Mask: When a DHCP server is not requested or is requested but not
available, the PTP Module will use this Network Mask. In the format “#.#.#.#”
with no leading zeroes or spaces, where each ‘#’ is a decimal integer from the
range [0,255].
Default Gateway: When a DHCP server is not requested or is requested but not
available, the PTP Module will use this Default Gateway. In the format “#.#.#.#”
with no leading zeroes or spaces, where each ‘#’ is a decimal integer from the
range [0,255].
Configuring PTP Contracts
1.
Navigate to the Contract tab of the GB PTP Edit window.
484 SecureSync User Reference Guide
APPENDIX

Spectracom SecureSync Specifications

General

Model	SecureSync
Time Reference	GPS, GLONASS, BeiDou, Galileo, IRIG, NTP, PTP, 1PPS
Disciplines	GNSS, IRIG, PTP, NTP, SyncE
Inputs	GPS, GLONASS, BeiDou, Galileo, IRIG, NTP, PTP, 1PPS
Outputs	NTP, PTP, 1PPS, IRIG
Protocols	PTP, NTP, SNMP, SSH, HTTPS
Form Factor	1U Rack-mount
Redundancy	Optional redundant power supply
Security Features	Password protection, access control lists, SSH, HTTPS, SNMPv3, NTP authentication, PTP authentication
Power Supply	100-240 VAC, 50-60 Hz
Operating Temperature	0°C to +50°C
Dimensions	44.45 mm (H) x 482.6 mm (W)
