The Edit window allows the configuration of the following settings:
RS-485 Address: [0-31]
Communication Input/Output: Status Window
To view the address of an RS-485 communication input/output, go to its Status window. For
instructions, see: "Viewing Input/Output Configuration Settings" on page347.
The Web UI list entry for this card is: RS-485 Comm.
The name of the Input/Output is: RS-485Comm[number].
Note: SecureSync starts numbering I/O ports with 0 (only 1PPS and 10MHz out-
puts start at1, because of the built-in outputs).
The Status window displays the following settings:
RS-485 Address: [0-31]
SecureSync User Reference Guide 511
APPENDIX
