Spectracom SecureSync User Manual

Data Format 2 with either a Time Zone Offset or automatic DST rule will result in
an error message.
E x a m p l e m e s s a g e :
CR LF IQYY ^ DDD ^ HH:MM:SS.SSS ^ LD
Where:
CR Carriage Return
LF Line Feed
I Time Sync Status (space, ?, *)
Q Quality Indicator (space, A, B, C, D)
YY Year without century (99, 00, 01, etc.)
^ Space separator
DDD Day of Year (001-366)
HH Hours (00-23 UTC time)
: Colon separator
MM Minutes (00-59)
: Colon separator
SS (00-60)
. Decimal separator
SSS Milliseconds (000-999)
L Leap Second indicator (space, L)
D Daylight Saving Time Indicator (S,I,D,O)
The leading edge of the first character (CR) marks the on-time point of the data stream.
The time synchronization status character (I) is defined as described below:
? When the receiver is unable to track any satellites and the time synchronization lamp is red.
* When the receiver time is derived from the battery backed clock or set manually through the Setup Port
Interface.
SecureSync User Reference Guide 525
APPENDIX

Spectracom SecureSync Specifications

General

Model	SecureSync
Time Reference	GPS, GLONASS, BeiDou, Galileo, IRIG, NTP, PTP, 1PPS
Disciplines	GNSS, IRIG, PTP, NTP, SyncE
Inputs	GPS, GLONASS, BeiDou, Galileo, IRIG, NTP, PTP, 1PPS
Outputs	NTP, PTP, 1PPS, IRIG
Protocols	PTP, NTP, SNMP, SSH, HTTPS
Form Factor	1U Rack-mount
Redundancy	Optional redundant power supply
Security Features	Password protection, access control lists, SSH, HTTPS, SNMPv3, NTP authentication, PTP authentication
Power Supply	100-240 VAC, 50-60 Hz
Operating Temperature	0°C to +50°C
Dimensions	44.45 mm (H) x 482.6 mm (W)
