Format Encoding Modulation Carrier Coded Expressions Bit rate
Time Frame Inter-
val
IRIG-E E003 DCLS N/A BCD
TOY
, SBS 10 pps 1 sec
IRIG-E E004 DCLS N/A BCD
TOY
, BCD
YEAR
, CF and
SBS
10 pps 1 sec
IRIG-E E005 DCLS N/A BCD
TOY
, BCD
YEAR
, and CF 10 pps 1 sec
IRIG-E E006 DCLS N/A BCD
TOY
, BCD
YEAR
10 pps 1 sec
IRIG-E E007 DCLS N/A BCD
TOY
, BCD
YEAR
, and SBS 10 pps 1 sec
IRIG-E E110 AM 100 Hz BCD
TOY
, CF and SBS 10 pps 1 sec
IRIG-E E111 AM 100 Hz BCD
TOY
, CF 10 pps 1 sec
IRIG-E E112 AM 100 Hz BCD
TOY
10 pps 1 sec
IRIG-E E113 AM 100 Hz BCD
TOY
, SBS 10 pps 1 sec
IRIG-E E114 AM 100 Hz BCD
TOY
, BCD
YEAR
, CF and
SBS
10 pps 1 sec
IRIG-E E115 AM 100 Hz BCD
TOY
, BCD
YEAR
, and CF 10 pps 1 sec
IRIG-E E116 AM 100 Hz BCD
TOY
, BCD
YEAR
10 pps 1 sec
IRIG-E E117 AM 100 Hz BCD
TOY
, BCD
YEAR
, and SBS 10 pps 1 sec
IRIG-E E120 AM 100 Hz BCD
TOY
, CF and SBS 10 pps 1 sec
IRIG-E E121 AM 1kHz BCD
TOY
, CF 10 pps 10 sec
IRIG-E E122 AM 1kHz BCD
TOY
10 pps 10 sec
IRIG-E E123 AM 1kHz BCD
TOY
, SBS 10 pps 10 sec
IRIG-E E124 AM 1kHz BCD
TOY
, BCD
YEAR
, CF and
SBS
10 pps 10 sec
IRIG-E E125 AM 1kHz BCD
TOY
, BCD
YEAR
, and CF 10 pps 10 sec
IRIG-E E126 AM 1kHz BCD
TOY
, BCD
YEAR
10 pps 10 sec
IRIG-E E127 AM 1kHz BCD
TOY
, BCD
YEAR
, and SBS 10 pps 10 sec
IRIG-G
IRIG-G G001 DCLS N/A BCD
TOY
, CF 10000
pps
10 msec
IRIG-G G002 DCLS N/A BCD
TOY
10000
pps
10 msec
