Universal synchronous asynchronous receiver transmitter (USART) UM0306

412/519

Bit 1

RWU: Receiver Wake-Up.

This bit determines if the USART is in mute mode or not. It is set and cleared by

software and can be cleared by hardware when a wake-up sequence is

recognized.

0: Receiver in active mode

1: Receiver in mute mode

Notes:

1: Before selecting Mute mode (by setting the RWU bit) the USART must first

receive a data byte, otherwise it cannot function in Mute mode with wake-up by Idle

line detection.

2: In Address Mark Detection Wake-Up configuration (WAKE bit=1) the RWU bit

cannot be modified by software while the RXNE bit is set.

Bit 0

SBK: Send Break.

This bit set is used to send break characters. It can be set and cleared by

software. It should be set by software, and will be reset by hardware during the

stop bit of break.

0: No break character is transmitted

1: Break character will be transmitted
