Toyota 22R-E - Page 416

No.1 water by–pass pipe x Cylinder block
for union bolt (2WD)
for relief valve (4WD)
for bolt
No.4 timing belt cover x No.3 timing belt cover
LH engine mounting bracket x Cylinder block
RH engine mounting bracket x Cylinder block
Cold start injector tube x Cold start injector
No.1 injection manifold x Exhaust Manifold
Air intake chamber stay x Air intake chamber
Exhaust crossover pipe x Exhaust Manifold
Oil pressure sender gauge x Cylinder block
Engine coolant drain plug x Cylinder block
Water by–pass outlet x Intake manifold
Air intake chamber stay x Cylinder head
Camshaft bearing cap x Cylinder head
Connecting rod cap x Connecting rod
No.3 timing belt cover x Cylinder head
Cylinder block x Oil cooler relief valve
Rear oil seal retainer x Cylinder block
Cylinder head cover x Cylinder head
Air intake chamber x Intake manifold
No.2 idler pulley x Intake manifold
Oil dipstick guide x Cylinder head
Main bearing cap x Cylinder block
EGR pipe x Air intake chamber
Oil pan x Rear ail seal retainer
PAIR reed valve x Cylinder head
Rear end plate x Cylinder block
Intake manifold x Cylinder head
Engine hanger x Cylinder head
EGR valve x Air intake chamber
Crankshaft x Drive plate (A/T)
Oil strainer x Main bearing cap
Oil filter union x Cylinder block
No.3 fuel pipe x Delivery pipe
No.2 fuel pipe x Delivery pipe
Delivery pipe x Cylinder head
EGR pipe x Exhaust manifold
Water pump x Cylinder block
Crankshaft x Flywheel (M/T)
Oil pump x Cylinder block
Oil cooler x Cylinder block
for short bolt
for long bolt
Oil pan x Cylinder block
Oil strainer x Oil pump
Oil pan x Oil pump
for bolt
for nut
–ENGINE ENGINE MECHANICAL
EG2–139
