Xerox Phaser 790

1. Setting up the Phaser 790 Unpacking the Printer
1-20 Xerox Phaser 790
d. Press the Anti-rotation button to release the rotating chambers.
0
301027C-WOL
e. Turn the knob in the direction of the arrow, until it stops.
The next strip labeled G is visible.
0
301028C-WOL
f. Repeat steps c through e until all four of the strips labeled G are
removed from the Dry Ink carrousel.
g. Pull open Paper Tray 1 until it stops. Remove the two spacers
labeled C and F, shown below.
301023B-WOL
0
