1. Setting up the Phaser 790 Adding memory to the Printer

1-52 Xerox Phaser 790

8. Insert the left-hand side Printer panel into place as shown below.

301215a

9. Press the panel closed and slide it to the left.

301216

10. Reinstall the three screws into the side panel.

301070
