16 Help / Support
16.1 Take Screenshot
16-1
HW1485509
HW1485509
16 Help / Support
16.1 Take Screenshot
Users can take a screenshot of the current screen’s contents and save the
screenshot as a graphics file in PNG format. Screenshots cannot be
taken without the USB memory stick.
1. Insert USB memory stick
2. Select {Help / Support} under {MENU}
3. Select {Screenshot}
4. Message appears {Screenshot Saved Picture of screen saved to
file…}
5. Date and time that the screenshot is taken will be included in the file
name
A screenshot can also be taken by pressing the membrane jogging speed
[FAST] and [SLOW] keys together.
16.2 YASKAWA Representative
YASKAWA provides support for its products on a global basis. The
technical phone and email list can be accessed from the Smart Pendant.
Please contact your local YASKAWA Representative. A YASKAWA
Representatives can be found on the back cover of this manual.
The YASKAWA Representatives may request log files from the Smart
Pendant. Logs can be exported to a USB memory stick by pressing the
button {EXPORT LOG FILES…} at the bottom left of the screen.
