ADTRAN Total Access 5000 Deployment Guide

65K510DEP08-1A 4-1
Section 4
EoCu Provisioning
Scope of this Section
ThissectiondetailsthestepsneededtoprovisionEoCuusingtheSHDSLEthernetintheFirst
Mile(EFM)AccessModuleandtheNetVanta838.This sectionprovidestheminimumconfig‐
urationfortraffictopassfromtheGigESMporttoanEthernetportontheNetVanta838.
In this Section
Thissectioncontainsthefoll owingtopics:
Table 4-1. Section 4 Topics
Topic See Page
EoCuOverview 4‐2
ProvisioningSummary 4‐3
Provisionthe32‐PortSHDSLEFM 4‐4
ProvisiontheEFMBondingProtectionModuleAdministrationState 4‐6
CreateanEFMBondingGroup 4‐7
CreateanEVCCrossConnect 4‐14
EnableEFMBondingProtection 4‐17
LogOntotheNetVanta838 4‐20
CreateanEVC 4‐21
CreateanEVCMap 4‐24
ProvisionPolicersintheNetVanta838 4‐27
ProvisionMACAddressLimitingandAging 4‐30
DisableUnusedNetVanta838Interfaces 4‐31
SavetheNetVanta838Provisioning 4‐34

ADTRAN Total Access 5000 Specifications

Interfaces

craft interface	DB-9 RS-232 Electrical Interface (Async)
admin interface	DB-9 RS-232 DTE Electrical Interface (Async with Modem Control Signals)
network management port	DB-9 RS-232 DTE Electrical Interface (Async)
ethernet interface	10Bt
external alarm inputs	16

Operating Environment

operating temperature	-40°C to +65°C
storage temperature	-40°C to +70°C
relative humidity	Up to 95%, non-condensing

Weight and Dimensions

height	9.25 in.
width	0.08 in.
depth	9.5 in.
weight	0.6 lbs.
