ADTRAN Total Access 5000 Deployment Guide

Section 4, EoCu Provisioning - Provision the 32-Port SHDSL EFM
65K510DEP08-1A 4-5
NOTE
Ifconnectedto the shelfwherethemoduleresides,theshelfnumberis
typically1.
2. FromtheGlobalConfigurationprompt,provisionthemoduleadministrationstateby
performingoneofthefollowingcommands:
•Type
no slot shutdown <shelf/slot>,andpressENTERtotaketheslotInService
•Type
slot shutdown maintenance <shelf/slot>,andpressENTERtotakethe 
slotOutofServiceMaintenance
•Type
slot shutdown <shelf/slot>,andpressENTERtotaketheslotOutof
Service,Unassigned
3. FromtheGlobalConfigurationprompt,type
interface shdsl <shelf/slot/port>,
andpress
ENTER.
4. ToconfiguretheCircuitID,type
description LINE,andpressENTER.
5. ProvisiontheSHDSLportadministrationstatebyperformingoneofthefollowing
commands:
•Type
no shutdown,andpressENTERtotaketheportInService
•Type
shutdown maintenance,andpressENTERtotaketheportOutofService,
Maintenance
•Type
shutdown,andpressENTERtotaketheportOutofService,Unassigned
6. Tosetthealarmthresholds,type
thresholds [cvc|es|losws|ses|uas] [15
minute|24 hour] <0-2147483647>
,andpressENTER.
Table4‐3providesthesyntaxandalarmthresholddefinitionsforarg_1andarg_2.
7. Repeatsteps3‐8foreachSHDSLportthatneedstobeprovisioned.
8. Type
end,andpressENTERtoreturntotheEnableprompt.
Table 4-3. 32-Port SHDSL EFM Alarm Thresholds
Syntax Definition
arg_1 Selectthethresholdtoconfigurethefollowing:
•cvc‐CodeViolationCount
•es‐ErroredSeconds
•losws‐LossofSyncWordSeconds
•ses‐SeverelyErroredSeconds
•uas‐UnavailableSeconds
arg_2 Enterthesecondalarmthresholdtooneofthefollowing:
•15‐minute‐Thisreportsanyviolationswithina15‐minutetime
frame.Validvaluesare0‐2147483647.
•24‐hour‐Thisreportsanyviolationswithina24‐hourtimeframe.
Validvaluesare0‐2147483647.

ADTRAN Total Access 5000 Specifications

Interfaces

craft interface	DB-9 RS-232 Electrical Interface (Async)
admin interface	DB-9 RS-232 DTE Electrical Interface (Async with Modem Control Signals)
network management port	DB-9 RS-232 DTE Electrical Interface (Async)
ethernet interface	10Bt
external alarm inputs	16

Operating Environment

operating temperature	-40°C to +65°C
storage temperature	-40°C to +70°C
relative humidity	Up to 95%, non-condensing

Weight and Dimensions

height	9.25 in.
width	0.08 in.
depth	9.5 in.
weight	0.6 lbs.
