ADTRAN Total Access 5000 Deployment Guide

Section 5, BSM Provisioning - Create an EVC Cross Connect
65K510DEP08-1A 5-13
EVC Guidelines
Toensurevalidprovisioning,observethefollowingguidelineswhencreatinganEVC:
•AnEVCisappliedonlyifthe statusisRunning(asindicatedintheshowevcoutput),
whichindicatesthattheconditionsarevalid
•TwoEVCsareconsideredtobeduplicateiftheybothhavethesamevaluesforthe
S‐tag.
•NotwoEVCscanhavethesamename
•TheS‐tagvaluefortheEVCcannotequalthemanagementVLANID
Table5‐6displaystheavailableS‐tagsintheTotalAccess5000.
Provisioning Steps
Thisprocessestablishesaconnectionbetweenthephysicalport(Gigabit‐Ethernetportonthe
GigESM)andthevirtualnetwork(thePPPgroupconnectedtothecustomerrouter).
TocreatetheEVC,completethefollowingprocedure:
1. FromtheEnableprompt,type
configure terminal,andpressENTERtogettotheGlo‐
balConfigurationprompt.
2. FromtheGlobalConfigurationprompt,type
evc <evc_name>,andpressENTER.
3. FromtheEVCI n terface Configurationprompt,type
s-tag <2-4094>,andpressENTER
tosettheS‐tagofthe EVC.
4. FromtheEVCI n terface Configurationprompt,type
connect men-port gigabit-
ethernet 1/A/1
,andpressENTERtoconnecttheactiveSMNet1interfacetotheEVC.
NOTE
Theconnect men-port gigabit-ethernetcommandentryappliestothe
activeGigESM,independent ofwhichGigESMisactuallyspecified,inan
Active/Standbyconfiguration.
5. FromtheEVCI n terface Configurationprompt,type
no shutdownandpressENTERto
enabletheEVC.
6. FromtheEVCI n terface Configurationprompt,type
endandpressENTERtoreturntothe
Enableprompt.
TheEVCisnowcreated.
7. FromtheEnableprompt,type
show evc <evc_name>,andpressENTERtoviewthenew
EVCstatus.
ThePPPgroupandEVChasbeencreatedandenabled.
Table 5-6. Available S-tag Range
S-tag Function
0,1,4095 Reserved
2–4094 EVPLsandInbandManagementVLAN
3072 InternalManagementVLAN(Default)

ADTRAN Total Access 5000 Specifications

Interfaces

craft interface	DB-9 RS-232 Electrical Interface (Async)
admin interface	DB-9 RS-232 DTE Electrical Interface (Async with Modem Control Signals)
network management port	DB-9 RS-232 DTE Electrical Interface (Async)
ethernet interface	10Bt
external alarm inputs	16

Operating Environment

operating temperature	-40°C to +65°C
storage temperature	-40°C to +70°C
relative humidity	Up to 95%, non-condensing

Weight and Dimensions

height	9.25 in.
width	0.08 in.
depth	9.5 in.
weight	0.6 lbs.
