Total Access 5000 Business Services Deployment Guide

2-12 65K510DEP08-1A

NOTE

TheAMIO2 ‐CH50PsupportstheCOMBOA2+24‐PortandRPOTS24‐Port

AccessModules.

AMIO2-CH64P Rear Panel

TheAMIO2‐CH64PcoverstwomoduleslotsontherearoftheTotalAccess5000Chassis.The

AMIO2‐CH64Pisdesignedtoholdtwostandardentry64‐pinmalechampconnectorcables.

Forstandardentry,the cableexitsthe90°connectorhoodonthepin1endofthemalechamp



connector.

NOTE

Push‐throughpanelsareprovidedwithfourCaptiveChampScrewsfor

installationoftwoconnectorstothepanel.Usetwoscrewsforeachconnector,

oneforthemountingbracket,thesecondtosecuretheconnectortothepanel.

TheCaptiveCham pScrewprovidedwiththecablemustbereplacedifitis

nota0.35inchscrew.

LMIO2-CH64B Rear Panel

TheLMIO2‐CH64Bisaninterconnectfortwolinemoduleslotsontherearofthechassis.The

LMIO2‐CH64Bmoduleprovidesmetallicaccessto32four‐wirecircuitsperaccessmodule

installedforamaximumof32four‐wirecircuits.Two64‐pinmale90°champconnectors

attachtothe

LMIO2‐CH64B,andprovideconnectionandstabilizationbetweenmodulesin

theTotalAccess5000Chassisandexternalcableconnectionsthatuse64‐pinconnectors.For

standardentry,thecableexitsthe90°connectorhoodonthepin1endofthemalechamp

connector.

LMIO2-CH50D Rear Panel

TheLMIO2‐CH50DisaninterconnectfortwolinemoduleslotsontherearoftheTotalAccess

5000Chassis.TheLMIO2‐CH50Dprovidesmetallicaccessto8four‐wirecircuitsperaccess

moduleinstalledforamaximumof16four‐wirecircuits.Two50‐pinmale90°champ

connectorsattach

totheLMIO2‐CH50D,andprovideconnectionandstabilizationbetween

modulesintheTotalAccess5000Chassisandexternalcableconnectionsthatuse50‐pin

connectors.Forstandardentry,thecableexitsthe90°connectorhoodonthepin1endofthe

malechampconnector.

LMIO2 HD DS1 Rear Panel

TheLMIO2HDDS1RearPanelisaninterconnectfortwolinemoduleslotsontherearofthe

TotalAccess5000Chassis.TheLMIO2HDDS1providesmetallicaccessto32four‐wire

circuitsperaccessmodule.Four2mmconnectorsprovideaccesstotheDSXloops.Theupper

connectors

providethetransmitpair,andthelowerconnectorsprovidethereceivepair.

ADTRAN Total Access 5000 Specifications

Interfaces

craft interface	DB-9 RS-232 Electrical Interface (Async)
admin interface	DB-9 RS-232 DTE Electrical Interface (Async with Modem Control Signals)
network management port	DB-9 RS-232 DTE Electrical Interface (Async)
ethernet interface	10Bt
external alarm inputs	16

Operating Environment
