ADTRAN Total Access 5000 - Gigabit Ethernet 8-Port Line Module Description; DS1 PPP;MLPPP 32-Port Line Module Description

Section 2, Installation - Install the Front Panel Modules
65K510DEP08-1A 2-23
NOTE
TheRPRLineModulein thehighernumberedslotisdesignatedasthe East
interfaceandthelowernumberedslotisdesignatedastheWestinterface.
Gigabit Ethernet 8-Port Line Module Description
TheGigabitEthernet8‐PortLineModule(GE8‐PortLM)providestheEoFsolutionssimilarto
theEoCuandEoTDM.TheGE8PortLMallowssubtendingofnetworkchanneltermination
equipment(NCTE)toprovideBusinessEthernetservices.TheGE8PortLMinterfacestothe
SMGigEon
theTotalAccess5000shelfbackplanetoprovide1G,2.5Gand5Gbandwidth.
TheGE8PortLMcanbedeployedinaredundantconfigurationthroughtheuseofaTotal
Access5000LMIO2HighSpeedRearPanel.TheLMIO2panelprovidesacontrolpath
betweentheredundantmodules.
Whenthe
GE8PortLMisusedforredundantapplications,theGE8]PortLMsmustbe
installedinadjacentslotswiththeleftmostGE8PortLMinanoddnumberedslot(e.g.,
1and
2,21and22).
TheGE8PortLMhaseightfrontpanelSFPcagesthatprovideinputsformaximuminterface
flexibility.
TheGE8PortLMcanreceivetimingfromtheSMGigEviathebackplane,andtransmitthis
timingoutofanyoftheeightfaceplateportsusingtheSyncEformat.The
modulewillnot
receivetimingonanyofitsfaceplateports.
NOTE
WhenusingtheGE8‐PortLMtoroutedatatoanadjacentGE8‐PortLM, an
LMIO2HighSpeedRearPanelmustbeinstalledpriortoinsertionofthe GE
8‐PortLMintotheTotalAccess5000Chassis.
DS1 PPP/MLPPP 32-Port Line Module Description
TheDS1PPP/MLPPP32‐PortLineModule(DS1PPP/MLPPP32‐Port)provides32DS1lines
andsupportsPoint‐to‐PointandMulti‐LinkPoint‐to‐Pointprotocols.The32DS1sare
intendedforin‐plantuseandhavenofuseorlightningprotection.
NOTE
•TheDS1PPP/MLPPP32‐Portcanbeinstalledinanyslot(excludingslots
labeled11,12/SCM,SMA,andSM B)oftheTotalAccess5000Chassis.If
installingonlyoneDS1PPP/MLPPP,itisreco mmendedthatitbeinstalled
inanoddslot.
•PriortoinstallingtheDS1PPP/MLPPP32
‐Port,installaLineModule
Input/OutputDualHDDS1DividedPairRearPanelora LineModule
Input/OutputDualChamp64‐PinBridgedRearPanel.
