ADTRAN Total Access 5000 Deployment Guide

Total Access 5000 Business Services Deployment Guide
5-16 65K510DEP08-1A
Provisioning Steps
TocreatetheEVCmapontheTotalAccess5000,completethefollowingsteps:
1. FromtheEnableprompt,type
configure terminal,andpressENTERtoaccesstheGlo‐
balConfigurationprompt.
2. FromtheGlobalConfigurationprompt,type
evc-map WORD <shelf/slot>,andpress
ENTERtocreateanEVCmapinthespecifiedshelfandslot,whereWORDisthenameof
thenewEVCmap.
NOTE
Ifcreatinganamewithspaces,quotesmustbeused.Forexample,evc-map
“test map” 1/21.
3. FromtheEVCMapInterfaceConfigurationprompt,type
connect evc WORD,andpress
ENTERtoconnecttheEVCmaptotheEVC,whereWORDisthealiasoftheEVC.
4. FromtheEVCMapInterfaceConfigurationprompt,type
connect uni ppp-group
<shelf/slot/group>
,andpressENTERtoconnecttheEVCmaptothePPPgroup.
Table5‐7displaysthelistofvariablesforconnectingthePPPgroup.
5. FromtheEVCMapInterfaceConfigurationprompt,type
match dscp <0-63>,and
press
ENTER.
Thematchdscp<0‐63>commandspecifiestheDSCPtomatchfortrafficreceivedfrom
thecustomer(PPPgroup).
NOTE
•MultipleDSCPvaluescanbelisted,sothatseveralmapscanbemappedto
aMENpriorityva lueinonestepratherthanseveral.Forexample,the
command,
match dscp 5,12,24-37,wouldbevalid
•ProvisioningoftheDSCPmatchingcriteriaisoptional.IfaDSCPmatching
criteriaisnotspecifiedforanEVCmap,thenalltrafficcomingfromthe
PPPgroupmatchesthe gi venEVCmap,andthatmapisusedinstead.If,
foraparticularPPPgroup,therearemaps
thatspecify theDSCPandone
thatdoesnot,theEVCmapwithoutaDSCPspecifierrec ei vesanytraffic
thatdoesnotmatchtheotherEVCmaps
•If DSCP traffic received from the customer that doesnot match a
configuredmap,itisstillpassedontotheEVCVLAN,withpriorityzero.
6. FromtheEVCMapInterfaceConfigurationprompt,type
men-pri <0-7>,andpress
ENTER.
Table 5-7. PPP Group Connecting Variables
Syntax Description
shelf Entertheshelfnumber.Ifprovisioningasingle‐nodeconfiguration,
enter1.
slot EntertheslotnumberoftheDS3module.
group EntertheauniquegroupnumberofthenewPPPgroup.

ADTRAN Total Access 5000 Specifications

Interfaces

craft interface	DB-9 RS-232 Electrical Interface (Async)
admin interface	DB-9 RS-232 DTE Electrical Interface (Async with Modem Control Signals)
network management port	DB-9 RS-232 DTE Electrical Interface (Async)
ethernet interface	10Bt
external alarm inputs	16

Operating Environment

operating temperature	-40°C to +65°C
storage temperature	-40°C to +70°C
relative humidity	Up to 95%, non-condensing

Weight and Dimensions

height	9.25 in.
width	0.08 in.
depth	9.5 in.
weight	0.6 lbs.
