ADTRAN Total Access 5000 Deployment Guide

Appendix J, GigE Star Provisioning - Remote Terminal (RT) Provisioning
65K510DEP08-1A J-13
4. Repeatsteps2and3fortheGE4‐PortLineModuleintheevenslot.
Provision the DS3 Unchannelized EFM 4-Port Line Module
Thissubsectiondetailsthefollowing information:
•ProvisiontheDS3UnchannelizedEFM4‐PortLineModule
•ProvisiontheUplinkIdentifer
•ProvisiontheTimingSource
Provision the DS3 Unchannelized EFM 4-Port Line Module
Administration Status
TableJ‐3displaysthethreeadministrationstatesandshowstheequivalentServiceStatefrom
priorreleases.
Tosetthemoduleadministrationstate,completethefollowing:
1. FromtheTotalAccess5000Mainmenu,select
System CLI,andpressENTER.
2. FromtheCLImenu,select
CLI Command Entry,andpressENTER.
Thefollowingresponseiddisplayed:
Use EXIT to exit CLI session.
3. SelectYtoentertheCLIcommandinterface.
4. LoginagainusingthedefaultADM IN andPASSWORDoptions.TheCLIpromptis
displayed.
5. Type
enable,andpressENTERtoenabletheprivilegedcommands.
6. FromtheEnableprompt,type
configure terminal,andpressENTER.toaccessthe
GlobalConfigurationprompt.
Table J-6. DS3 Unchannelized EFM 4-Port Module Administration States
Command Previous Description
no shutdown
InService
Inthe
no shutdownstate,traffic
passesandalarmsaregenerated.
shutdown maintenance
OutofService,Main‐
tenance
Intheshutdown maintenance
state,trafficpassesbutnoalarmsare
generated.
shutdown
OutofService,Unas‐
signed
Inthe
shutdownstate,notraffic
passesandnoalarmsaregenerated.

ADTRAN Total Access 5000 Specifications

Interfaces

craft interface	DB-9 RS-232 Electrical Interface (Async)
admin interface	DB-9 RS-232 DTE Electrical Interface (Async with Modem Control Signals)
network management port	DB-9 RS-232 DTE Electrical Interface (Async)
ethernet interface	10Bt
external alarm inputs	16

Operating Environment

operating temperature	-40°C to +65°C
storage temperature	-40°C to +70°C
relative humidity	Up to 95%, non-condensing

Weight and Dimensions

height	9.25 in.
width	0.08 in.
depth	9.5 in.
weight	0.6 lbs.
