ADTRAN Total Access 5000 Deployment Guide

Appendix D, TWAMP Provisioning - Current TWAMP Status
65K510DEP08-1A D-5
NOTE
Ifthe startofthetestsessionisneverreac hed,onlythecontroltimeoutis
used.
Thedefaultvalueis900.
5. FromtheTWAMPResponderConfigurationprompt,type
control timeout <1-
65535>
,andpressENTERtosetthecontrolsessionrespondertimeoutinseconds.
Thecontroltimeoutissimilartothetestsessiontimeout,butthecontroltimeoutapplies
tothecontrolsessionphaseofTWAMP.ThecontrolsesionphaseusestheTCPprotocol.
Thedefaultvalueis900.
6. FromtheTWAMPResponderConfigurationprompt,enablethe
TWAMPresponder,by
typing
no shutdown,thenpressENTER.
7. Type
exitandpressENTERtoexittotheGlobalConfigurationprompt.
Current TWAMP Status
ToviewthecurrentTWAMPstatus,completethefollowing:
FromtheEnableprompt,type
show probe responder twamptoseethecurrentTWAMP
status:
NetVanta800/8000#show probe responder twamp
TWAMP Reflector status
State: Enabled
Control Port: 862
Timeouts
Control: 900 seconds
Test: 900 seconds
Test Packets
Received: 745
Sent: 745
Sessions
Active: 3 of 6
Opened: 15
Closed: 12
Rejected: 13
TableD‐2contains adescriptionofthestatisticslistedintheexampleabove:

ADTRAN Total Access 5000 Specifications

Interfaces

craft interface	DB-9 RS-232 Electrical Interface (Async)
admin interface	DB-9 RS-232 DTE Electrical Interface (Async with Modem Control Signals)
network management port	DB-9 RS-232 DTE Electrical Interface (Async)
ethernet interface	10Bt
external alarm inputs	16

Operating Environment

operating temperature	-40°C to +65°C
storage temperature	-40°C to +70°C
relative humidity	Up to 95%, non-condensing

Weight and Dimensions

height	9.25 in.
width	0.08 in.
depth	9.5 in.
weight	0.6 lbs.
