ADTRAN Total Access 5000 Deployment Guide

65K510DEP08-1A 5-1
Section 5
BSM Provisioning
Scope of this Section
ThissectiondetailsthestepsneededtoprovisionaBSMapplicationusing theCHDS3PPP/
MLPPP3‐PortLineModuleortheDS1PPP/MLPPP32‐PortLineModule.
In this Section
Thissectioncontainsthefoll owingtopics:
Table 5-1. Section 5 Topics
Topic See Page
BSMOverview 5‐2
ProvisioningSummary 5‐3
ProvisiontheLineModule 5‐4
CreateaPoint‐To‐PointProtocolGroup 5‐7
CreateanEVCCrossConnect 5‐12
CreateanEVCMapontheTotalAccess5000 5‐15

ADTRAN Total Access 5000 Specifications

Interfaces

craft interface	DB-9 RS-232 Electrical Interface (Async)
admin interface	DB-9 RS-232 DTE Electrical Interface (Async with Modem Control Signals)
network management port	DB-9 RS-232 DTE Electrical Interface (Async)
ethernet interface	10Bt
external alarm inputs	16

Operating Environment

operating temperature	-40°C to +65°C
storage temperature	-40°C to +70°C
relative humidity	Up to 95%, non-condensing

Weight and Dimensions

height	9.25 in.
width	0.08 in.
depth	9.5 in.
weight	0.6 lbs.
