ADTRAN Total Access 5000 Deployment Guide

Section 6, EoTDM Provisioning - Create an EFM Bonding Group
65K510DEP08-1A 6-7
Table6‐3displaysthelistofvariablesfortheEFMbondinggroup.
4. FromtheEFMConf igurationprompt,type
exit,andpressENTERtoreturntothe
ApplicationConfigurationprompt.
Verify Bonding Group Creation
Toverifythatthebondinggroupwascreated,anddeterminetheslotandgroupIDassigned
tothegroup,performoneofthefollowing:
•FromtheEnableprompt,type
show interfaces efm-group,andpressENTER toview
allEFMbondinggroupsintheTotalAccess5000
•FromtheEnableprompt,type
show table interfaces efm-group,andpressENTER
toviewatable(withlimitedEFMgroupinformation)
•FromtheEnableprompt,type
show efm-group 1,andpressENTERtoseethelinks
assignedtoallgroupsintheshelfalongwiththeprovisionedgrouprates
Table 6-3. EFM Bonding Group Variables
Syntax Description
WORD Enterthename(upto50alphanumericcharacterswithnospacesorspe‐
cialcharacters)ofthebondinggroup.
EFMlinks EntertheEFMlinkstoaddtothebondinggroup.Eachlinkmustbeinthe
slot/port:channelformat.
active‐links‐minimum Enterthenumberoflinksinthegrouprequiredtoprovide
theupstream
anddownstreamrates.Anyadditionallinkswillbehotstandbylinks.
upstream/downstream Thevaluesaftertheupstreamanddownstreamkeywordsarethe
upstreamanddownstreamratesforthebondinggroup.

ADTRAN Total Access 5000 Specifications

Interfaces

craft interface	DB-9 RS-232 Electrical Interface (Async)
admin interface	DB-9 RS-232 DTE Electrical Interface (Async with Modem Control Signals)
network management port	DB-9 RS-232 DTE Electrical Interface (Async)
ethernet interface	10Bt
external alarm inputs	16

Operating Environment

operating temperature	-40°C to +65°C
storage temperature	-40°C to +70°C
relative humidity	Up to 95%, non-condensing

Weight and Dimensions

height	9.25 in.
width	0.08 in.
depth	9.5 in.
weight	0.6 lbs.
