ADTRAN Total Access 5000 Deployment Guide

Total Access 5000 Business Services Deployment Guide
N-4 65K510DEP08-1A
NOTE
Step17shouldonlybeperformedonRTnodes.
New Remote Terminal Addition
ToaddanewRemoteTerminaltotheERPSring,completethefollowing:
NOTICE
Thesestepsmustbeperformedinthisorder.Ifnot,trafficwillbe lostonthe
ring.
1. LogontotheRemoteTerminalNode.
2. ConfiguretheERPSinterfaceonthenewRemoteTerminal.
Formoreinformation,referto“RingInterfaceCreation”onpage N‐3.
3. FromtheGlobalConfigurationprompt,type
ethernet default interface erps 1/
B/1
,andpressENTER.
ThiscommandconfigurestheuplinkontheRemoteTerminalNode.
4. PutaManualSwitch(MS)followedbyaForcedSwitch(FS)ononeendofthespan
wheretheRemoteTerminalNodewillbeinserted.Usethefollowingcommandsto
completethisstep:
a. FromtheGlobalConfigurationprompt,type
force manual-switch erps east
1/B/1
,andpressENTER.
b. FromtheERPSInterfaceConfigurationprompt,type
force-switch east,and
press
ENTER.
5. PutaFSontheotherendofthespan.
6. PhysicallyconnectthenewRemoteTerminalNodetothering.
7. RemovetheFSonbothnodes.FromtheERPSInterfaceConfigurationprompt,type
no
force-switch east
,andpressENTER.
System Timing Configuration for Central Office Node
ToconfigurethesystemtimingfortheCentralOfficeNode,completethefollowing:
1. FromtheEnableprompt,type
configure terminal,andpressENTERtoaccesstheGlo‐
balConfigurationprompt.
2. FromtheGlobalConfigurationprompt,type
system-timing 1,andpressENTER.
3. FromtheSystem‐TimingConfigurationprompt,type
external primary hop-count
0
,andpressENTER.
4. FromtheSystem‐TimingConfigurationprompt,type
external primary priority
0
,andpressENTER.
5. FromtheSystem‐TimingConfigurationprompt,type
external primary type bits-
d4
,andpressENTER.
6. FromtheSystem‐TimingConfigurationprompt,type
external primary quality
stratum 1
,andpressENTER.

ADTRAN Total Access 5000 Specifications

Interfaces

craft interface	DB-9 RS-232 Electrical Interface (Async)
admin interface	DB-9 RS-232 DTE Electrical Interface (Async with Modem Control Signals)
network management port	DB-9 RS-232 DTE Electrical Interface (Async)
ethernet interface	10Bt
external alarm inputs	16

Operating Environment

operating temperature	-40°C to +65°C
storage temperature	-40°C to +70°C
relative humidity	Up to 95%, non-condensing

Weight and Dimensions

height	9.25 in.
width	0.08 in.
depth	9.5 in.
weight	0.6 lbs.
