ADTRAN Total Access 5000 Deployment Guide

Appendix L, RPR Provisioning - Central Office Terminal (COT) Node Provisioning
65K510DEP08-1A L-5
Figure L-3. RPR Line Module Main Menu
Provision the RPR Line Module Service State
ThecardservicestatemustbesettoIS.
NOTE
TheRPRLineModuleswor kinaMaster/Slaverelationship.Theactive
(Master)mustbeIS,andthestandby(Slave)mustintheIS,Standby‐Hot(IS,
S‐H)state.IfthemodulesareOut‐of‐Service,the spanshouldbedownand
thecardshouldnotparticipate inanyredundancy orring 
operation,nor
shoulditparticipateindatabasemirroring.
Tosetthecardservicestate,completethefollowingprocedure:
1. FromtheRPRLineModulemenu,select
Provisioning,andpressENTER.
FigureL‐4displaystheRPRLineModuleProvisioningmenu.
TID: HSV00001 Total Access 5000 System MM/DD/YY HH:MM
Unacknowledged Alarms: None Unit Number: 1
RPR Line Module: Active
1. Configuration
2. Provisioning
3. Status
4. Test
5. Alarms
6. Performance Monitoring
7. Event Log
Selection :
'?' - System Help Screen

ADTRAN Total Access 5000 Specifications

Interfaces

craft interface	DB-9 RS-232 Electrical Interface (Async)
admin interface	DB-9 RS-232 DTE Electrical Interface (Async with Modem Control Signals)
network management port	DB-9 RS-232 DTE Electrical Interface (Async)
ethernet interface	10Bt
external alarm inputs	16

Operating Environment

operating temperature	-40°C to +65°C
storage temperature	-40°C to +70°C
relative humidity	Up to 95%, non-condensing

Weight and Dimensions

height	9.25 in.
width	0.08 in.
depth	9.5 in.
weight	0.6 lbs.
