ADTRAN Total Access 5000 Deployment Guide

Total Access 5000 Business Services Deployment Guide
1-8 65K510DEP08-1A
Ethernet over TDM Overview
TheendtoendEthernetoverTDM(EoTDM)solution(Figure1‐4andFigure1‐5)encom‐
passesthelatestMetroEthernetForum(MEF)certifiedEthernetintheFirstMile(EFM)over
TimeDivisionMultiplexed(TDM)NetworkTerminationUnits(NTU),whichleverages
existingTDM/SDH/SONETfacilitiestoofferextendedreachCarrier
Ethernetupto135Mbps.
TheEoTDMoffersthefollowingfeatures:
• ConsistentOperations,Administration,andMaintenance(OAM)
•Trafficmanagementandflow‐throughprovisioning
• Resiliencythroughdynamiccircuitremovalandrestoration
• ElectricalandOpticalEthernetconnectionstothecustomer
Figure 1-4. EoTDM DS3 4-Port General Application Diagram
SONET
Multiplexer
(Central Office)
Total Access 5000
Central Office
DS3s
EoTDM
General
Application Diagram
Router
SONET
Multiplexer
(Customer Side)
NetVanta 873
Customer Site

ADTRAN Total Access 5000 Specifications

Interfaces

craft interface	DB-9 RS-232 Electrical Interface (Async)
admin interface	DB-9 RS-232 DTE Electrical Interface (Async with Modem Control Signals)
network management port	DB-9 RS-232 DTE Electrical Interface (Async)
ethernet interface	10Bt
external alarm inputs	16

Operating Environment

operating temperature	-40°C to +65°C
storage temperature	-40°C to +70°C
relative humidity	Up to 95%, non-condensing

Weight and Dimensions

height	9.25 in.
width	0.08 in.
depth	9.5 in.
weight	0.6 lbs.
