ADTRAN Total Access 5000 - Provision the S-Tag Tag Protocol Identifier (TPID); Provision the Default Gateway

Total Access 5000 Business Services Deployment Guide
3-16 65K510DEP08-1A
Provision the Default Gateway
Toprovisionthedefaultgateway,completethefollowingprocedure:
1. FromtheEnableprompt,type
configure terminal,andpressENTERtoaccesstheGlo‐
balConfigurationprompt.
2. FromtheGlobalConfigurationprompt,type
ip default-gateway A.B.C.D,and
press
ENTERtosetthesystemdefaultgateway.
NOTE
Thedefaultgatewaymustmatchthe gatewayaddressofeithertheInbandor
Ethernetinterface,whichistypicallytheroutertowhichth einterfaceis
connected.
3. Type
end,andpressENTERtoreturntotheEnableprompt.
Provision the S-tag Tag Protocol Identifier (TPID)
TheS‐tagTPIDistypicallyafunctionofthetypeofexternalswitchorrouterthatisconnected
totheGigESM.Ifnotset,settheS‐tagTPIDtothedesiredvalue.TheS‐tagTPIDindicatesthe
EthertypeusedtoidentifytheS‐VLANtags.Tochange
theS‐tagTPID,completethe following
procedure:
1. FromtheEnableprompt,type
configure terminal,andpressENTERtoaccesstheGlo‐
balConfigurationprompt.
2. FromtheGlobalConfigurationprompt,type
ethernet s-tag-tpid HHHH,andpress
ENTERtosettheS‐tagTPIDtoHHHH,whereHHHHisinhexadecimal.
NOTE
•ThevalidTPIDrangesare0x8000‐0xFFFFusing4hexadecimaldigits.
•ThedefaultTPIDvalueis0x8100.
3. Type
end,andpressENTERtoreturntotheEnableprompt.
