ADTRAN Total Access 5000 Deployment Guide

Section 4, EoCu Provisioning - Create an EVC Cross Connect
65K510DEP08-1A 4-15
Provisioning Steps
Thisprocessestablishesaconnectionbetweenthephysicalportandthevirtualnetwork.
TocreatetheEVC,completethefollowingprocedure:
1. FromtheEnableprompt,type
configure terminal,andpressENTERtogettotheGlo‐
balConfigurationprompt.
2. FromtheGlobalConfigurationprompt,type
evc <evc_name>,andpressENTER.
3. FromtheEVCI n terface Configurationprompt,type
s-tag <1-4094>,andpressENTER
tosettheS‐tagofthe EVC.
4. FromtheEVCI n terface Configurationprompt,type
connect men-port gigabit-
ethernet 1/A/1
,andpressENTERtoconnecttheactiveSMNet1interfacetotheEVC.
NOTE
Thecon ne ctmen‐portgigabit‐ethernetcommandentryappliestotheactive
GigESM,independentofwhichGigE SMisactuallyspecified,inanAc tive/
Standbyconfiguration.
5. FromtheEVCI n terface Configurationprompt,type
connect men-port efm-group
<shelf/slot/group>
,andpressENTERtoconnecttheEFMbondinggrouptotheEVC.
NOTE
TheEFMbondinggroupnamecanbeusedinlieuof the shelf/slot/group
designation.
6. FromtheEVCI n terface Configurationprompt,type
no shutdownandpressENTERto
enabletheEVC.
7. FromtheEVCI n terface Configurationprompt,type
endandpressENTERtoreturntothe
Enableprompt.

ADTRAN Total Access 5000 Specifications

Interfaces

craft interface	DB-9 RS-232 Electrical Interface (Async)
admin interface	DB-9 RS-232 DTE Electrical Interface (Async with Modem Control Signals)
network management port	DB-9 RS-232 DTE Electrical Interface (Async)
ethernet interface	10Bt
external alarm inputs	16

Operating Environment

operating temperature	-40°C to +65°C
storage temperature	-40°C to +70°C
relative humidity	Up to 95%, non-condensing

Weight and Dimensions

height	9.25 in.
width	0.08 in.
depth	9.5 in.
weight	0.6 lbs.
