ADTRAN Total Access 5000 Deployment Guide

Total Access 5000 Business Services Deployment Guide
4-8 65K510DEP08-1A
4. FromtheEFMConf igurationprompt,typeexit,andpressENTERtoreturntothe
ApplicationConfigurationprompt.
Verify Bonding Group Creation
Toverifythatthebondinggroupwascreated,anddeterminetheslotandgroupIDassigned
tothegroup,performoneofthefollowing:
•FromtheEnableprompt,type
show interfaces efm-group,andpressENTER toview
allEFMbondinggroupsintheTotalAccess5000
•FromtheEnableprompt,type
show table interfaces efm-group,andpressENTER
toviewatable(withlimitedEFMgroupinformation)
•FromtheEnableprompt,type
show efm-group 1,andpressENTERtoseethelinks
assignedtoallgroupsintheshelfalongwiththeprovisionedgrouprates
EFM Bonding Group Example
Theexamplebelowcreatesabondinggroupwhichincludesslot1,ports3and5,thendisplays
thegroupstatus.
NOTE
Ifthereisa problemwiththecreatio nofthegroup,anerro rmessagewill
followthecreatecommand.Otherwise,itissuccessfulifnoerro rmessage
followsthecommand.
TA5000# application
TA5000(app)# ez-efm 1
TA5000(app-ez-efm 1)# create my_bonding_group link 1/3,1/5 upstream 5000
downstream 5000 active-links-minimum 1
TA5000(app-ez-efm 1)# exit
TA5000(app)# exit
TA5000# show interfaces efm-group
EFM Group 1/1/2 {MY_BONDING_GROUP} is ENABLED and UP
Provisioned Links : 1/3,1/5
Active Links : 1/3,1/5
Inhibited Links : None
UpStream Data Rate : 5120
DownStream Data Rate : 5120
Table 4-5. EFM Bonding Group Variables
Syntax Description
WORD
Enterthename(upto50alphanumericcharacterswithnospacesorspe‐
cialcharacters)ofthebondinggroup.
EFM links
EntertheEFMlinkstoaddtothebondinggroup.Eachlinkmustbeinthe
slot/portformatandseparatedbycommas.
active-links-min-
imum
Enterthenumberoflinksinthegrouprequiredtoprovidetheupstream
anddownstreamrates.Anyadditionallinkswillbehotstandbylinks.
upstream/down-
stream
Thevaluesaftertheupstreamanddownstreamkeywordsarethe
upstreamanddownstreamratesforthebondinggroup.

ADTRAN Total Access 5000 Specifications

Interfaces

craft interface	DB-9 RS-232 Electrical Interface (Async)
admin interface	DB-9 RS-232 DTE Electrical Interface (Async with Modem Control Signals)
network management port	DB-9 RS-232 DTE Electrical Interface (Async)
ethernet interface	10Bt
external alarm inputs	16

Operating Environment

operating temperature	-40°C to +65°C
storage temperature	-40°C to +70°C
relative humidity	Up to 95%, non-condensing

Weight and Dimensions

height	9.25 in.
width	0.08 in.
depth	9.5 in.
weight	0.6 lbs.
