ADTRAN Total Access 5000 Deployment Guide

Section 2, Installation - Install and Connect the Rear Panel Components
65K510DEP08-1A 2-13
LMIO2 High-Speed Rear Panel
TheLMIO2HighSpeedRearPanelprovidesahigh‐speeddatapathfromafrontpanelSFPto
anadjacentGE4‐Port,GE8‐Port,orRPRLineModule.
Inapacketringconfiguration,theLMIO2High‐SpeedRearPanelisusedtoprovideahigh
speeddatalinkand
handshakecommunicationsbetweentwoTotalAccess 5000RPRLine
Modules.Bothapplicationscanalsobeusedforautomaticprotectionswitching(APS).
LMIO2 DS3 BNC Rear Panel
TheLMIO2DS3BNCRearPanelisaseriesofI/OmodulesfortheATMDS3LineModuleson
therearoftheTotalAccess5000chassis.TheLMIO2DS3BNCRearPanelprovides
Tx(out)
and
Rx(in)BNCconnectorsfortheATMDS3.
NOTE
TheLMIO2DS3BNCRearPanelonlysupportstheDS3ATMLineModule.
Installing a DS3 BNC Rear Panel
ToinstalltheDS3BNCRearPanel,completethefollowing:
1. Ifinstalled,removetherearblankpanel.
2. PositiontheDS3BNCRearPanelontherearalignmentpinsonthebackoftheTotal
Access5000Chassis.
3. Usingthe0.335inchscrewsonthetopandthe0.725inchCaptivePanelscrew
onthe
bottom,securetheDS3BNCRearPaneltothechassis.
4. InstallthetransmitandreceiveDS3cables.
WARNING
!
Tomeet NEBSLevel3andprovide properairflow andfiltration,the
applicablerearpanelmustbeinstalledinanyoccupiedslot,andafrontand
rearpanelblankmustbeinstalledinanyemptyslots.

ADTRAN Total Access 5000 Specifications

Interfaces

craft interface	DB-9 RS-232 Electrical Interface (Async)
admin interface	DB-9 RS-232 DTE Electrical Interface (Async with Modem Control Signals)
network management port	DB-9 RS-232 DTE Electrical Interface (Async)
ethernet interface	10Bt
external alarm inputs	16

Operating Environment

operating temperature	-40°C to +65°C
storage temperature	-40°C to +70°C
relative humidity	Up to 95%, non-condensing

Weight and Dimensions

height	9.25 in.
width	0.08 in.
depth	9.5 in.
weight	0.6 lbs.
