ADTRAN Total Access 5000 Deployment Guide

Total Access 5000 Business Services Deployment Guide
A-2 65K510DEP08-1A
Link Aggregation Provisioning
Toprovisionforlinkaggregation,completethefollowingprocedure:
NOTICE
Toaddcrossconnectstotheaggregationbridge,reprovisioningisrequired.
1. DisableLACP.
LACPmessagesmustbetemporarilydisabledwhilesettingupthelinkaggregation
group.Formoreinformation,referto“DisableLACP”onpage A‐2.
2. Ifneeded,enableadditionalGigabit‐Ethernetinterfaces.
Formoreinformation,referto“EnableNetworkInterfaces”onpage A
‐3.
3. CreateaLinkAggregation groupandaddGigabit‐Ethernetphysicalinterfaces.
Formoreinformation,referto“CreateaLinkAggregationGroup”onpage A‐3.
4. EnableLACP.
Formoreinformation,referto“EnableLACP”onpage A‐3.
5. Configurethedefaultnetworkinterfacetothenewlycreatedlinkaggregationgroup .
Formoreinformation,refer
to“ConfigureDefaultNetworkInterface”onpage A‐4.
6. CreateanEVCandlinkittothelinkaggregationgroup.
Formoreinformation,referto“ConfigureEVCs”onpage A‐4.
7. RedirectanycreatedEVCstoalinkaggregationgroup.
Formoreinformation,referto“RedirectEVCs”onpage A‐5.
Disable LACP
TodisableLACPforallactivegigabit‐ethernetports,completethefollowingprocedure:
1. FromtheEnableprompt,type
configure terminal,andpressENTERtoaccesstheGlo‐
balConfigurationprompt.
2. FromtheGigabitEthernetInterfaceConfigurationprompt,type
interface gigabit-
ethernet 1/A/1
,andpressENTERtoaccesstheGigabitEthernetInterfaceConfiguration
prompt.
3. FromtheGigabitEthernetInterfaceConfigurationprompt,type
no lacp mode,and
press
ENTERtodisableLACPforthegigabit‐ethernetinterface.
4. Repeatsteps2to3todisableLACPforallactivegigabit‐ethernetinterfaces
5. FromtheGigabitEthernetInterfaceConfigurationprompt,type
end,andpressENTERto
returntotheEnableprompt.

ADTRAN Total Access 5000 Specifications

Interfaces

craft interface	DB-9 RS-232 Electrical Interface (Async)
admin interface	DB-9 RS-232 DTE Electrical Interface (Async with Modem Control Signals)
network management port	DB-9 RS-232 DTE Electrical Interface (Async)
ethernet interface	10Bt
external alarm inputs	16

Operating Environment

operating temperature	-40°C to +65°C
storage temperature	-40°C to +70°C
relative humidity	Up to 95%, non-condensing

Weight and Dimensions

height	9.25 in.
width	0.08 in.
depth	9.5 in.
weight	0.6 lbs.
