ADTRAN Total Access 5000 Deployment Guide

Total Access 5000 Business Services Deployment Guide
2-28 65K510DEP08-1A
NetVanta 873 Description
TheNetVanta873DS3EFMisa MEFcompliant,EFMbondedNTUdesignedforcost‐effective
deploymentofdataservicestosmallandmediumsizebusinessessupportinguptothree
DS3s.TheNetVan ta873acceptsunchannelizedDS3sanddelivers10/100Base‐TEthernet,as
wellasaGigabitEthernetSFPportfor
customerLANextension.TheDS3sareterminatedin
BNCconnectorsandoperateatthestandard44.736Mbpsdatarate.TheNetVanta873
providesanaggregatedatarateupto134.208MbpsoverasingleEFMbondinggroup.
NetVanta 8044 Description
TheNetVanta8044BusinessServices(NTE)isaGigabit‐EthernetNTEorEthernetAccess
Device(EAD)thatsupportspointtopointdeploymentforGigabit‐Ethernetservicesfromthe
TotalAccess5000platformoranyotherEthernet‐serviceplatformthatsupportsstandard‐
basedEthernetoverFiber(EoF)implementations.TheADTRANEoFsolution
isaMEF
compliantsolutionsupportingfamiliaroperationtoolsbasedonConnectivityFault
Management(CFM)andPe rformanceMonitoring(PM)EthernetOAMstandards,aswellas,
leadingauthenticationstandardssuchasRADIUSandTACACS+.
Installation Steps
TowallmountorrackmounttheNetVanta800,completethefollowingprocedure:
1. AttachmountingbracketstothesideoftheNetVanta800inthecorrectorientationfor
eitherrackmountorwallmountusingthetwoscrewsprovidedforeachbracket.
•Torackmounttheunit,usetheappropriaterack‐typescrewstomounttheNetVanta

800intotherack.
•Towallmounttheunit,securetheNetVanta800tothewallwithappropriatescrews.
2. Connecttheframegroundfromtheframegroundlugontheupperrightrearpanelof
theNetVanta800totheequipmentrackgroundingscreworotherappropriate
groundingconnection.
3. Makepowerconnectionsto
theNetVanta800.
NOTE
•Areadilyaccessibledisconnectdevice,suchasarackmountfuseandalarm
panelthatissuitablyapprovedand rated,shouldbeincorporatedinto the
fixedwiring
•C onnecttoareliablygrounded ±48VD Cor±24VDC source thatis
electricallyisolatedfromtheACsource
•The branchcircuitovercurrentprotection
shouldbeaslow‐blowfuseor
circuitbreaker
a. DeterminewhichfusepairsaretosupplypowertotheNetVanta800.
b. RemovethefusesfromtheAandBslotsforthepair.
c. Connect RET A,PWR A,RET B,andPWR B tothepowerconnector.PWR refersto
respective±48VDCor±24VDCpowersources;RET referstorespectivereturns.
4. Apply
powerandcheckvoltages.

ADTRAN Total Access 5000 Specifications

Interfaces

craft interface	DB-9 RS-232 Electrical Interface (Async)
admin interface	DB-9 RS-232 DTE Electrical Interface (Async with Modem Control Signals)
network management port	DB-9 RS-232 DTE Electrical Interface (Async)
ethernet interface	10Bt
external alarm inputs	16

Operating Environment

operating temperature	-40°C to +65°C
storage temperature	-40°C to +70°C
relative humidity	Up to 95%, non-condensing

Weight and Dimensions

height	9.25 in.
width	0.08 in.
depth	9.5 in.
weight	0.6 lbs.
