Total Access 5000 Business Services Deployment Guide
B-2 65K510DEP08-1A
49-Self Reach on AWG24
FigureB‐1displaysthee‐SHDSLreachfora49‐selfnoiseonAWG24.
Figure B-1. Single Pair Theoretical 49–self Reach on AWG24
Realistic Deployment Reach
FigureB‐2displaysasinglepairrealisticdeploymentreachforAWG24.
Figure B-2. Single Pair Realistic Deployment Reach on AWG24
e-SHDSL Reach: 49-self Noise on AWG24
0
0
3
6
9 12
15
18 21
5000
4000
3000
2000
1000
6000
Rate (kbps)
Reach (kft of AWG24)
e-SHDSL 32-TCPAM
e-SHDSL 16-TCPAM
SHDSL
3dB bandwidth:
32-TCPAM->
Data Rate/8
Data Rate/6
16-TCPAM->
6000
5000
4000
3000
2000
1000
0
0
3
6
9
12
15
18
21 24
Rate (kbps)
Reach (kft of AWG24)
49 disturbers
12 disturbers
SpM limits
SHDSL/e-SHDSL Realistic Deployment Reach

ADTRAN Total Access 5000 Specifications

Interfaces

craft interface	DB-9 RS-232 Electrical Interface (Async)
admin interface	DB-9 RS-232 DTE Electrical Interface (Async with Modem Control Signals)
network management port	DB-9 RS-232 DTE Electrical Interface (Async)
ethernet interface	10Bt
external alarm inputs	16

Operating Environment

operating temperature	-40°C to +65°C
storage temperature	-40°C to +70°C
relative humidity	Up to 95%, non-condensing

Weight and Dimensions

height	9.25 in.
width	0.08 in.
depth	9.5 in.
weight	0.6 lbs.
