ADTRAN Total Access 5000 Deployment Guide

Appendix N, ERPS Provisioning - ERPS Configuration
65K510DEP08-1A N-3
Ring Interface Creation
Toconfiguretheringinterface,completethefollowing:
1. AfterestablishingaconnectionwiththeSCM,pressinganykeydisplaystheTotalAccess
5000Systemlogonscreen.
NOTE
Theaccountnameandpasswordfieldsarecase‐sensitive.
Thedefaultaccountnameis“A D M I N ” andthepasswordis“PASSWORD.”
Otherdefaultaccounts are:READONLY,READWRITE, andTEST. An
accountwithADMINprivilegesisrequiredtochangetheaccountnameand
password.
2. Typethedefaultaccountname,
ADMIN(ortheconfiguredaccountnamewithSystem
Administratorprivileges),andpress
ENTER.
3. Typethedefaultpassword,
PASSWORD(ortheconfiguredpassword),andpressENTER.
4. TheTotalAccess5000MainMenuisdisplayed.
5. FromtheMainMenu,select
System CLIandpressENTER.
6. OntheCLImenu,verifythattheTelnetPortis2008.Thisisthedefaulttelnetdesignation.
Ifthisisnotdisplayed,select
CLI Telnet Port optionandsettheportto2008.PresstheESC
keytoreturntotheCLImenu.
7. FromtheCLImenu,select
CLI Command EntryandpressENTER.
8. Thefollowingresponseisdisplayed:
Use EXIT to exit CLI session.
9. Select
“Y” to enter the CLI command interface.
10. Type
enable,andpressENTERtoenableprivilegedcommands.
11. FromtheEnableprompt,type
configure terminal,andpressENTERtoaccessthe
GlobalConfigurationprompt.
12. FromtheGlobalConfigurationprompt,type
interface erps 1/A/1,andpressENTER.
NOTE
IfSM‐BisactiveontheNode,thecommandchangestointerfaceerps1/B/1 .
13. FromtheERPSInterfaceConfigurationprompt,type
west interface
ten-gigabit-ethernet 1/A/2
,andpressENTER.
14. FromtheERPSInterfaceConfigurationprompt,type
east interface
ten-gigabit-ethernet 1/B/2
,andpressENTER.
15. FromtheERPSInterfaceConfigurationprompt,type
no shut,andpressENTERtosetthe
portInService.
16. FromtheERPSInterfaceConfigurationprompt,type
exit,andpressENTER.
17. FromtheGlobalConfigurationprompt,type
ethernet default interface erps 1/
B/1
,andpressENTER.

ADTRAN Total Access 5000 Specifications

Interfaces

craft interface	DB-9 RS-232 Electrical Interface (Async)
admin interface	DB-9 RS-232 DTE Electrical Interface (Async with Modem Control Signals)
network management port	DB-9 RS-232 DTE Electrical Interface (Async)
ethernet interface	10Bt
external alarm inputs	16

Operating Environment

operating temperature	-40°C to +65°C
storage temperature	-40°C to +70°C
relative humidity	Up to 95%, non-condensing

Weight and Dimensions

height	9.25 in.
width	0.08 in.
depth	9.5 in.
weight	0.6 lbs.
