ADTRAN Total Access 5000 Deployment Guide

Total Access 5000 Business Services Deployment Guide
J-6 65K510DEP08-1A
Provision the Timing Source
Toprovisionthetimi ngsource,completethefollowing:
1. FromtheEnableprompt,type
configure terminal,andpressENTERtoaccesstheGlo‐
balConfigurationprompt.
2. FromtheGlobalConfigurationprompt,type
system-timing <shelf>,andpress
ENTER.
3. FromtheSystem‐TimingConfigurationprompt,type
source primary loop-a
interface t3 <shelf/slot/port>
,andpressENTER.
4. FromtheSystem‐TimingConfigurationprompt,typesource secondary loop-b
interface t3 <shelf/slot/port>
,andpressENTER.
NOTE
ADTRANrecommendshavingtheprimaryandsecondarytimingsourceson
differentDS3portsandadjacentredundantslots.
Provision the T1 8-Port Line Module
Thissubsectiondetailsthefollowing information:
•T18‐PortLineModuleProvisioningDefaults
• AccesstheT18‐PortLineModule
•ProvisiontheT18‐PortLineModuleServiceState
•ProvisiontheT18‐PortAccessLineModuleDS1InterfaceServiceState
•ProvisiontheUplinkIdentifier
•ProvisiontheDS1Interface
T1 8-Port Line Module Provisioning Defaults
WhentheT18‐PortLineModuleisinstalledinaTotalAccess5000shelf,theSCMqueriesthe
system(localandclusteredshelves)tosynchronizeitsdatabase.Nouserinterventionis
requiredforthisprocess.ProvisioningishandledwithoutuserentryifAuto‐Provisioningis
enabled.Otherwise,provisioningmustbe
accomplishedmanuallythroughtheSCMmenu
system.
TableJ‐4showstheminimumlistoffactorydefaultsandvaluesthatareloadedafterinstal‐
lationandself‐test.Thesedefaultsandvaluesprovidetheminimumconfigurationforturnup
oftheT18‐PortLineModule.

ADTRAN Total Access 5000 Specifications

Interfaces

craft interface	DB-9 RS-232 Electrical Interface (Async)
admin interface	DB-9 RS-232 DTE Electrical Interface (Async with Modem Control Signals)
network management port	DB-9 RS-232 DTE Electrical Interface (Async)
ethernet interface	10Bt
external alarm inputs	16

Operating Environment

operating temperature	-40°C to +65°C
storage temperature	-40°C to +70°C
relative humidity	Up to 95%, non-condensing

Weight and Dimensions

height	9.25 in.
width	0.08 in.
depth	9.5 in.
weight	0.6 lbs.
