ADTRAN Total Access 5000 Deployment Guide

Total Access 5000 Business Services Deployment Guide
M-2 65K510DEP08-1A
Perform a Manual or Forced Switch
ToperformaForcedorManualSwitch,completethefollowing:
1. FromtheRPRLineModulemenu,select
Provisioning,andpressENTER.
2. FromtheProvisioningmenu,select
RPR Provisioning,andpressENTER.
FigureM‐1displaystheRPRProvisioningmenu.
.
Figure M-1. RPR Provisioning Menu
3. FromtheRPRProvisioningmenu,select
Protection Command,andpressENTER.
FigureM‐2displaystheCurrentProtectionmenu.
TID: TA5000 Total Access 5000 System MM/DD/YY hh:mm
Unacknowledged Alarms: None Node: 1
RPR Provisioning
1. Keepalive Timeout (ms) : 5
2. Wait to Restore Time (s) : 10
West East
3. Protection Holdoff Time (ms): 0 0
4. Protection Command : Idle Idle
5. Fairness Weight : 1 1
6. Reset Watermarks
Selection :
'?' - System Help Screen
