ADTRAN Total Access 5000 Deployment Guide

Section 2, Installation - Install and Connect the Rear Panel Components
65K510DEP08-1A 2-11
Install and Connect the Rear Panel Components
ThissubsectiondetailstheconnectionandinstallationoftheTotalAccess5000rearpanels.
Connect the SMIO3
Theplasticguardthatcoversthewire‐wrapterminalsontheSMIO3isasafetyfeaturethat
preventspersonnelandequipmentfromcontactingexposedvoltages.
NOTE
TheSMIO3isalreadyinstalledbutmustbeconnected.
Toremovetheguard,completethefollowingprocedure:
1. Usinga#1phillips‐headscrewdriver,removethethreescrewsthatsecuretheguard.
2. CarefullyremovetheguardbypullingitstraightfromtheSMIO3.
Toreinstalltheguard,reversethepreviousprocedures.
Inputandoutput
connectorsontheSMIO3consistofthefollowing:
• CommunicationsInterfacePorts–PhysicalinterfacestotheSCM,consistingofRS‐232‐
compatibleportsforAdminandNetworkManagementfunctions,andanEthernetLAN
forManagementfunctions
•TerminalBlockConnections–Labeledblocksofwire‐wrapterminalsforalarms,alarm
cutoff,
externalvoltage,clockfunctions,testbus,andshelflinkingfunctions
NOTE
RefertotheTotalAccess5000SwitchModuleI/O3(SMIO3)Installationand
MaintenancePractice(P/N61187051G1‐5)fordetailedinformation.
AMIO1 Blank Panel
TheAMIO1coversonemoduleslotontherearoftheTotalAccess5000Chassis.
Install the AMIO1 Blank Panel
ToinstalltheAMIO1Blank Panel,completethefollowingprocedure:
1. PositiontheAMIO1Blankontherearalignmentpinsonthebackofthechassisoverthe
appropriateslot.
1. UsingtheCaptivePanelScrews,securetheAMIO1Blank totherearofthechassis.
AMIO2-CH50P Rear Panel
TheAMIO2‐CH50Pcoverstwomoduleslotsontherearofthechassis.TheAMIO2‐CH50Pis
designedtoholdtwostandardentry50‐pinmalechampconnectorcables.Forstandardentry,
thecableexitsthe90°connectorhoodonthepin1endofthemalechampconnector.

ADTRAN Total Access 5000 Specifications

Interfaces

craft interface	DB-9 RS-232 Electrical Interface (Async)
admin interface	DB-9 RS-232 DTE Electrical Interface (Async with Modem Control Signals)
network management port	DB-9 RS-232 DTE Electrical Interface (Async)
ethernet interface	10Bt
external alarm inputs	16

Operating Environment

operating temperature	-40°C to +65°C
storage temperature	-40°C to +70°C
relative humidity	Up to 95%, non-condensing

Weight and Dimensions

height	9.25 in.
width	0.08 in.
depth	9.5 in.
weight	0.6 lbs.
